Forum Discussion
Brian_Saunders1
Altostratus
AltostratusSSL TPS Limits
Hello All,
We've been performing load testing for an application that is going to be deployed in the near future and during that load testing I noticed that our 8950 LTM going over the base license 500 tps for SSL, typically it would drop back down below the threshold pretty quickly never remaining above 500 for more than a second or so. After reviewing SOL6475: Overview of SSL TPS licensing limits it sounds like it might be best to upgrade the SSL license so that SSL connections aren't dropped? Just wanted to get other members experience with this.
Thanks,
Brian
HamishCirrocumulus
In my experience, when your SSL TPS averaged over 60 seconds, goes over 0.5 of the license, it's time to upgrade it...
SSL TPS is calculated on a 10ms time slice. Every 10ms you can perform 1/100th of the licensed value. Go over that value (e..g for a 500TPS license that limit is 5) in that 10ms interval, and you'll get dropped connections.
H
hooleylistCirrostratus
it sounds like it might be best to upgrade the SSL license so that SSL connections aren't dropped?Agreed 🙂
nitassEmployee
Is there a way to determine if a connection was dropped due to the SSL TPS being exceeded?
i am not aware of. there is counter in tmctl to show how many connections are dropped.
- Hamish
Yes.
The LTM logs (In /var/log/ltm) when it's dropping SSL connections due to license exceeded.
I'm not aware of any iRule event that would let you trap that though...
H
- Jazz007_235152
Nimbostratus
We currently have Bluecoat performing SSL and Reverse proxy. Is there any way to find out how much SSL TPS I am getting ?
