ASM Brute-Force - Common Username

Hi everyone, I'm trying to come up with a creative solution to an application login problem.  Only identified when we applied Brute-Force protection using Form-Based Auth. The Login Page has the fo...
  • Mark_van_D's avatar
    Mar 14, 2022

    Ok so turns out that part of the problem was with how I was using findstr.

    What was happening:


    set raw_password [findstr $payload $static::password_tag "9"]


    With the line above under the normal login process with: Content-Type: application/x-www-form-urlencoded

    this was correctly grabbing the password from the payload.

    But when the CAPTCHA changed this to: Content-Type: multipart/form-data

    It was capturing the password including the multipart boundary, therefore changing the Basic Auth header and causing a bunch of issues (not being able to solve the CAPTCHA at all, or in some cases allowing anything to be entered to solve).

    So we changed the password capture to break on "\r\n" which seems to have done the trick.

    The final iRule we ended up using was:


    when RULE_INIT {
        ## user-defined: size in bytes of HTTP request to parse
        set static::max_req_size 1048576
        ## the names of the tags for the username and password.
        set static::customerid_tag "customer_id"
        set static::username_tag "username"
        set static::password_tag "password"
        set static::login_url "/user_login.php"
    when HTTP_REQUEST {
        if { ([HTTP::method] eq "POST") && ([string tolower [HTTP::uri]] contains $static::login_url ) } {
        # Trigger collection for up to max_req_size of data
            set modify_response_content_type 1
        if {[HTTP::header "Content-Length"] ne "" && [HTTP::header "Content-Length"] <= $static::max_req_size } {
            set content_length [HTTP::header "Content-Length"]
            } else {
            set content_length $static::max_req_size
            # Check if $content_length is not set to 0
        if { $content_length > 0} {
            HTTP::collect $content_length
        # collect the incoming payload
        set payload [HTTP::payload]
        ## skipahead is set to fieldname +1 to avoid matching the equals sign.
        set raw_customerid [findstr $payload $static::customerid_tag "12" "&"]
        set raw_username [findstr $payload $static::username_tag "9" "&"]
        set raw_password [findstr $payload $static::password_tag "9" "\r\n"]
        set auth_header_b64 [b64encode "$raw_customerid-$raw_username:$raw_password"]
        HTTP::header insert "Authorization" "Basic $auth_header_b64"
        #Don't pass header to backend
        HTTP::header remove "Authorization"


    Don't forget to mask the values of the Authorization header in the ASM policy.
