Simplifying and Securing Network Segmentation with F5 Distributed Cloud and Nutanix Flow
Introduction Enterprises often separate environments—such as development and production—to improve efficiency, reduce risk, and maintain compliance. A critical enabler of this separation is network segmentation, which isolates networks into smaller, secured segments—strengthening security, optimizing performance, and supporting regulatory standards. In this article, we explore the integration between Nutanix Flow and F5 Distributed Cloud, showcasing how F5 and Nutanix collaborate to simplify and secure network segmentation across diverse environments—on-premises, remote, and hybrid multicloud. Integration Overview At the heart of this integration is the capability to deploy a F5 Distributed Cloud Customer Edge (CE) inside a Nutanix Flow VPC, establish BGP peering with the Nutanix Flow BGP Gateway, and inject CE-advertised BGP routes into the VPC routing table. This architecture provides full control over application delivery and security within the VPC. It enables selective advertisement of HTTP load balancers (LBs) or VIPs to designated VPCs, ensuring secure and efficient connectivity. By leveraging F5 Distributed Cloud to segment and extend networks to remote location—whether on-premises or in the public cloud—combined with Nutanix Flow for microsegmentation within VPCs, enterprises achieve comprehensive end-to-end security. This approach enforces a consistent security posture while reducing complexity across diverse infrastructures. In our previous article (click here) , we explored application delivery and security. Here, we focus on network segmentation and how this integration simplifies connectivity across environments. Demo Walkthrough The demo consists of two parts: Extending a local network segment from a Nutanix Flow VPC to a remote site using F5 Distributed Cloud. Applying microsegmentation within the network segment using Nutanix Flow Security Next-Gen. San Jose (SJ) serves as our local site, and the demo environment dev3 is a Nutanix Flow VPC with an F5 Distributed Cloud Customer Edge (CE) deployed inside: *Note: The SJ CE is named jy-nutanix-overlay-dev3 in the F5 Distributed Cloud Console and xc-ce-dev3 in the Nutanix Prism Central. On the F5 Distributed Cloud Console, we created a network segment named jy-nutanix-sjc-nyc-segment and we assigned it specifically to the subnet 192.170.84.0/24: eBGP peering is ESTABLISHED between the CE and the Nutanix Flow BGP Gateway in this segment: At the remote site in NYC, a CE named jy-nutanix-nyc is deployed with a local subnet of 192.168.60.0/24: To extend jy-nutanix-sjc-nyc-segment from SJ to NYC, simply assign the segment jy-nutanix-sjc-nyc-segment to the NYC CE local subnet 192.168.60.0/24 in the F5 Distributed Cloud Console: Effortlessly and in no time, the segment jy-nutanix-sjc-nyc-segment is now extended across environments from SJ to NYC: Checking the CE routing table, we can see that the local routes originated from the CEs are being exchanged among them: At the local site SJ, the SJ CE jy-nutanix-overlay-dev3 advertises the remote route originating from the NYC CE jy-nutanix-nyc to the Nutanix Flow BGP Gateway via BGP, and installs the route in the dev3 routing table: SJ VMs can now reach NYC VMs and vice versa, while continuing to use their Nutanix Flow VPC logical router as the default gateway: To enforce granular security within the segment, Nutanix Flow Security Next-Gen provides microsegmentation. Together, F5 Distributed Cloud and Nutanix Flow Security Next-Gen deliver a cohesive solution: F5 Distributed cloud seamlessly extends network segments across environments, while Nutanix Flow Security Next-Gen ensures fine-grained security controls within those segments: Our demo extends a network segment between two data centers, but the same approach can also be applied between on-premises and public cloud environments—delivering flexibility across hybrid multicloud environments. Conclusion F5 Distributed Cloud simplifies network segmentation across hybrid and multi-cloud environments, making it both secure and effortless. By seamlessly extending network segments across any environment, F5 removes the complexity traditionally associated with connecting diverse infrastructures. Combined with Nutanix Flow Security Next-Gen for microsegmentation within each segment, this integration delivers end-to-end protection and consistent policy enforcement. Together, F5 and Nutanix help enterprises reduce operational overhead, maintain compliance, and strengthen security—while enabling agility and scalability across all environments. This integration is coming soon in CY2026. If you’re interested in early access, please contact your F5 representative. Related URLs Delivering Secure Application Services Anywhere with Nutanix Flow and F5 Distributed Cloud | DevCentral F5 Distributed Cloud - https://www.f5.com/products/distributed-cloud-services Nutanix Flow Network Security - https://www.nutanix.com/products/flow
Configuration Assistance: Configure Email Alerts for HA Failover Events and Device Offline
We have a BIG-IP VE High Availability Pair deployed in Microsoft Azure. We need to configure the BIG-IP to automatically send an email notification to our Operations teams immediately when a Failover event occurs(When the unit goes from Active to Standby or Offline) Could you provide the recommended procedure for the configuration to trigger these email alerts?WAFaaS with SSL Orchestrator
Introduction Note: This article applies to SSL Orchestrator versions prior to 11.0. If using version 11.0 refer to the article HERE This use case allows you to insert F5 WAF functionality as a Service in the SSL Orchestrator inspection zone. WAFaaS is the ability to insert ASM profiles into the SSL Orchestrator Service Chain for Inbound Topologies. This configuration is specific to a WAF policy running on the SSL Orchestrator device. WAF and SSL Orchestrator consume significant CPU cycles so care should be given when deploying both together. It is also possible to deploy WAF as a service on a separate BIG-IP device, in which case you’d simply configure an inline transparent proxy service. The ability to insert F5’s WAF into the Service Chain presents a significant customer benefit. This guide assumes you already have WAF/ASM profile(s) configured, licensed and provisioned on BIG-IP and wish to add this functionality to an Inbound Topology. In order to run WAF and SSL Orchestrator on the same device you will need an LTM license with SSL Orchestrator as an add-on option. You cannot add a WAF license to an SSL Orchestrator stand-alone license. SSL Orchestrator does not directly support inserting F5 WAF policies into the Service Chain. However, the F5 platform is flexible enough to handle many custom use cases. In this case, the ICAP service configuration exposes a framework that is useful for any number of specialized patterns, including adding a WAF policy to an SSLO service chain. We will configure an ICAP Service and attach the WAF policy to it. Steps: Create ICAP Service Disable Strictness on the Service Disable TCP monitor for the ICAP Pool ICAP Adapt profiles removed from the Virtual Server Application Security Policy enabled and a Policy assigned under Security Step #1: Create ICAP Service Note: These instructions assume an SSL Orchestrator Topology and Service Chain are already deployed and working properly. These instructions simply add WAFaaS to the existing Service Chain. It is entirely possible to create the WAFaaS during the initial Topology creation, in which case you would create the service during the workflow, then make the necessary changes after the topology has been created. From the SSL Orchestrator Guided Configuration click Services then Add Scroll to the bottom, select Generic ICAP Service and click Add Give it a name, WAFaaS in this example For ICAP Devices click Add on the right Enter an IP Address, 198.19.97.1 in this example and click Done. Note: the IP address you use does not have to be the one above. It’s just a local, non-routable address used as a placeholder in the service definition. This IP address will not be used. IP addresses 198.19.97.0 to 198.19.97.255 are owned by network benchmark tests and located in private networks. Scroll to the bottom and click Save & Next. The next screen is the Services Chain List. Click the name of the Service Chain you wish to add WAF functionality to, ssloSC_ServiceChain in this example. Note: The order of the Services in the Selected column is the order in which SSL Orchestrator will pass decrypted data to the device. This can be an important consideration if you want some devices to see, or not see, the actions taken by the WAF Service. Select the WAFaaS Service and click the right arrow to move it to Selected. Click Save. Click Save & Next Click Deploy You should receive a Success message Step #2: Disable Strictness on the Service From the SSL Orchestrator Configuration screen select Services. Click the padlock to Unprotect Configuration. Note: Disabling Strictness on the ICAP Service is needed to modify it and attach the WAFaaS policy. Strictness must remain disabled on this service and disabling strictness on the service has no effect on any other part of the SSL Orchestrator configuration. Click OK to Unprotect the Configuration Step #3: Disable tcp monitor for the ICAP Pool From Local Traffic select Pools > Pool List Select the WAFaaS Pool Under Active Health Monitors select tcp and click >> to move it to Available. This removes the Pool’s Monitor because otherwise it would be marked as down or unavailable. Click Update Note: The Health Monitor needs to be removed because there is no actual ICAP service to monitor. Step #4: ICAP Adapt profiles removed from the Virtual Server From Local Traffic select Virtual Servers > Virtual Server List Locate the WAFaaS ICAP service that ends in “-t-4” virtual server and select it Set the Request Adapt Profile and Response Adapt Profile to None to disable the default ICAP Profiles Click Update Step #5: Application Security Policy enabled and a Policy assigned under Security For the WAFaaS-t-4 Virtual Server click the Security tab Set Application Security Policy to Enabled Select the Security Policy you wish to use. Click Update when done Note: In specific versions of SSL Orchestrator there is one extra configuration item that needs to be modified. This is NOT required in other versions. If this change is made, when performing an upgrade it is not necessarily required to back out this change. Required versions: SSLO version 5.9.15 available on TMOS 14.1.4 SSLO versions 6.0-6.5 available on TMOX 15.0.x Navigate to “Local Traffic ›› Profiles : Other : Service” Select the Service profile named “ssloS_WAFaaS-service” Change the “Type” from “ICAP” to “F5 Module” Conclusion The configuration is now complete. Using the WAFaaS this way is functionally the same as using it by itself. There are no known limitations to this configuration.
F5 ASM with fortisandbox
Hi i want to integrate f5 ASM with fortisandbox as a icap server for file upload inspection i found this articale https://support.f5.com/csp/article/K70941653 but Value of virus_header_name for fortisandbox is not mentioned any one has experince of integration with fortisandbox. please let me know if anyone know virus_header_name for fortisandbox
F5 Open telemetry issue
Hi all, we have the issue with TS on f5, we installed TS package, set up declaration but when we are checking f5 url/telemetry we dont see atribute which we should see in the attachment you can see the declaration we have used and posted on f5 expecting to see everything, but we see only some basic status, not eg: f5 pool active members, f5 pool availability we dont see any errors in /var/log/restnoded/restnoded.log and when we check url: localhost/mgmt/shared/telemetry/pullconsumer/metrics we see nothing useful. Any help would be appreciated.f5 AI Gateway pii-redactor not working
I am testing Ai Gateway by looking at NGINX Modern Apps Docs. I have verified that OWASP LLM 01, 07 are working, but 02 Sensitive Information Configuration does not seem to be working. The demo video also contains Sensitive Information related content. how config Sensitive Information masking for ai gateway? https://clouddocs.f5.com/training/community/nginx/html/class15/module6/module6.html The processor's log looks like this: {"time":"2025-04-11T00:55:04.71766415Z","level":"ERROR","msg":"applying config to component failed, rolling back","error":"failed to check processors: failed to fetch parameters for processor pii-redactor: unable to fetch parameters from url: http://aigw-processors-f5.devopschan.svc.cluster.local/api/v1/signature/f5/pii-redactor, got status: 404"} 2025/04/11 00:55:04 WARN will retry config apply in 5s (1 of 3) {"time":"2025-04-11T00:55:05.368088471Z","level":"INFO","msg":"successfully reported usage data"} {"time":"2025-04-11T00:55:09.767886333Z","level":"ERROR","msg":"applying config to component failed, rolling back","error":"failed to check processors: failed to fetch parameters for processor pii-redactor: unable to fetch parameters from url: http://aigw-processors-f5.devopschan.svc.cluster.local/api/v1/signature/f5/pii-redactor, got status: 404"} 2025/04/11 00:55:09 WARN will retry config apply in 5s (2 of 3) {"time":"2025-04-11T00:55:14.817815787Z","level":"ERROR","msg":"applying config to component failed, rolling back","error":"failed to check processors: failed to fetch parameters for processor pii-redactor: unable to fetch parameters from url: http://aigw-processors-f5.devopschan.svc.cluster.local/api/v1/signature/f5/pii-redactor, got status: 404"} configuration file : ... responseStages: - name: protect steps: - name: pii-redactor ... - name: pii-redactor type: external config: endpoint: http://aigw-processors-f5.devopschan.svc.cluster.local namespace: f5 version: 1 params: threshold: 0.2 # Default 0.2 allow_rewrite: true # Default false denyset: ["EMAIL","PHONE_NUMBER","STREETADDRESS","ZIPCODE"] ... thank you.
