20 TopicsF5 Distributed Cloud Customer Edge on F5 rSeries – Reference Architecture
Traditionally, to advertise an application to the internet or to connect applications across multi-cloud environments enterprises must configure and manage multiple networking and security devices from different vendors in the DMZ of the data center. CE on F5 rSeries is a single vendor, converged solution for all enterprise multi-cloud application connectivity and security needs.1.4KViews2likes2CommentsHow I Did it - Migrating Applications to Nutanix NC2 with F5 Distributed Cloud Secure Multicloud Networking
In this edition of "How I Did it", we will explore how F5 Distributed Cloud Services (XC) enables seamless application extension and migration from an on-premises environment to Nutanix NC2 clusters.800Views4likes0CommentsExperience the power of F5 NGINX One with feature demos
Introduction Introducing F5 NGINX One, a comprehensive solution designed to enhance business operations significantly through improved reliability and performance. At the core of NGINX One is our data plane, which is built on our world-class, lightweight, and high-performance NGINX software. This foundation provides robust traffic management solutions that are essential for modern digital businesses. These solutions include API Gateway, Content Caching, Load Balancing, and Policy Enforcement. NGINX One includes a user-friendly, SaaS-based NGINX One Console that provides essential telemetry and overseas operations without requiring custom development or infrastructure changes. This visibility empowers teams to promptly address customer experience, security vulnerabilities, network performance, and compliance concerns. NGINX One's deployment across various environments empowers businesses to enhance their operations with improved reliability and performance. It is a versatile tool for strengthening operational efficiency, security posture, and overall digital experience. on Delivery and Management NGINX One has several promising features on the horizon. Let's highlight three key features: Monitor Certificates and CVEs, Editing and Update Configurations, and Config Sync Groups. Let's delve into these in details. Monitor Certificates and CVE’s: One of NGINX One's standout features is its ability to monitor Common Vulnerabilities and Exposures (CVEs) and Certificate status. This functionality is crucial for maintaining application security integrity in a continually evolving threat landscape. The CVE and Certificate Monitoring capability of NGINX One enables teams to: Prioritize Remediation Efforts: With an accurate and up-to-date database of CVEs and a comprehensive certificate monitoring system, NGINX One assists teams in prioritizing vulnerabilities and certificate issues according to their severity, guaranteeing that essential security concerns are addressed without delay. Maintain Compliance: Continuous monitoring for CVEs and certificates ensures that applications comply with security standards and regulations, crucial for industries subject to stringent compliance mandates. Edit and Update Configurations: This feature empowers users to efficiently edit configurations and perform updates directly within the NGINX One Console interface. With Configuration Editing, you can: Make Configuration Changes: Quickly adapt to changing application demands by modifying configurations, ensuring optimal performance and security. Simplify Management: Eliminate the need to SSH directly into each instance to edit or update configurations. Reduce Errors: The intuitive interface minimizes potential errors in configuration changes, enhancing reliability by offering helpful recommendations. Enhance Automation with NGINX One SaaS Console: Integrates seamlessly into CI/CD and GitOps workflows, including GitHub, through a comprehensive set of APIs. Config Sync Groups: The Config Sync Group feature is invaluable for environments running multiple NGINX instances. This feature ensures consistent configurations across all instances, enhancing application reliability and reducing administrative overhead. The Config Sync Group capability offers: Automated Synchronization: Configurations are seamlessly synchronized across NGINX instances, guaranteeing that all applications operate with the most current and secure settings. When a configuration sync group already has a defined configuration, it will be automatically pushed to instances as they join. Scalability Support: Organizations can easily incorporate new NGINX instances without compromising configuration integrity as their infrastructure expands. Minimized Configuration Drift: This feature is crucial for maintaining consistency across environments and preventing potential application errors or vulnerabilities from configuration discrepancies. Conclusion NGINX One Cloud Console redefines digital monitoring and management by combining all the NGINX core capabilities and use cases. This all-encompassing platform is equipped with sophisticated features to simplify user interaction, drastically cut operational overhead and expenses, bolster security protocols, and broaden operational adaptability. Read our announcement blog for more details on the launch. To explore the platform’s capabilities and see it in action, we invite you to tune in to our webinar on September 25th. This is a great opportunity to witness firsthand how NGINX One can revolutionize your digital monitoring and management strategies.699Views4likes1CommentDeploying F5 Distributed Cloud Customer Edge in Red Hat OpenShift Virtualization
Introduction Red Hat OpenShift Virtualization is a feature that brings virtual machine (VM) workloads into the Kubernetes platform, allowing them to run alongside containerized applications in a seamless, unified environment. Built on the open-source KubeVirt project, OpenShift Virtualization enables organizations to manage VMs using the same tools and workflows they use for containers. Why OpenShift Virtualization? Organizations today face critical needs such as: Rapid Migration: "I want to migrate ASAP" from traditional virtualization platforms to more modern solutions. Infrastructure Modernization: Transitioning legacy VM environments to leverage the benefits of hybrid and cloud-native architectures. Unified Management: Running VMs alongside containerized applications to simplify operations and enhance resource utilization. OpenShift Virtualization addresses these challenges by consolidating legacy and cloud-native workloads onto a single platform. This consolidation simplifies management, enhances operational efficiency, and facilitates infrastructure modernization without disrupting existing services. Integrating F5 Distributed Cloud Customer Edge (XC CE) into OpenShift Virtualization further enhances this environment by providing advanced networking and security capabilities. This combination offers several benefits: Multi-Tenancy: Deploy multiple CE VMs, each dedicated to a specific tenant, enabling isolation and customization for different teams or departments within a secure, multi-tenant environment. Load Balancing: Efficiently manage and distribute application traffic to optimize performance and resource utilization. Enhanced Security: Implement advanced threat protection at the edge to strengthen your security posture against emerging threats. Microservices Management: Seamlessly integrate and manage microservices, enhancing agility and scalability. This guide provides a step-by-step approach to deploying XC CE within OpenShift Virtualization, detailing the technical considerations and configurations required. Technical Overview Deploying XC CE within OpenShift Virtualization involves several key technical steps: Preparation Cluster Setup: Ensure an operational OpenShift cluster with OpenShift Virtualization installed. Access Rights: Confirm administrative permissions to configure compute and network settings. F5 XC Account: Obtain access to generate node tokens and download the XC CE images. Resource Optimization: Enable CPU Manager: Configure the CPU Manager to allocate CPU resources effectively. Configure Topology Manager: Set the policy to single-numa-node for optimal NUMA performance. Network Configuration: Open vSwitch (OVS) Bridges: Set up OVS bridges on worker nodes to handle networking for the virtual machines. NetworkAttachmentDefinitions (NADs): Use Multus CNI to define how virtual machines attach to multiple networks, supporting both external and internal connectivity. Image Preparation: Obtain XC CE Image: Download the XC CE image in qcow2 format suitable for KubeVirt. Generate Node Token: Create a one-time node token from the F5 Distributed Cloud Console for node registration. User Data Configuration: Prepare cloud-init user data with the node token and network settings to automate the VM initialization process. Deployment: Create DataVolumes: Import the XC CE image into the cluster using the Containerized Data Importer (CDI). Deploy VirtualMachine Resources: Apply manifests to deploy XC CE instances in OpenShift. Network Configuration Setting up the network involves creating Open vSwitch (OVS) bridges and defining NetworkAttachmentDefinitions (NADs) to enable multiple network interfaces for the virtual machines. Open vSwitch (OVS) Bridges Create a NodeNetworkConfigurationPolicy to define OVS bridges on all worker nodes: apiVersion: nmstate.io/v1 kind: NodeNetworkConfigurationPolicy metadata: name: ovs-vms spec: nodeSelector: node-role.kubernetes.io/worker: '' desiredState: interfaces: - name: ovs-vms type: ovs-bridge state: up bridge: allow-extra-patch-ports: true options: stp: true port: - name: eno1 ovn: bridge-mappings: - localnet: ce2-slo bridge: ovs-vms state: present Replace eno1 with the appropriate physical network interface on your nodes. This policy sets up an OVS bridge named ovs-vms connected to the physical interface. NetworkAttachmentDefinitions (NADs) Define NADs using Multus CNI to attach networks to the virtual machines. External Network (ce2-slo): External Network (ce2-slo): Connects VMs to the physical network with a specific VLAN ID. This setup allows the VMs to communicate with external systems, services, or networks, which is essential for applications that require access to resources outside the cluster or need to expose services to external users. apiVersion: k8s.cni.cncf.io/v1 kind: NetworkAttachmentDefinition metadata: name: ce2-slo namespace: f5-ce spec: config: | { "cniVersion": "0.4.0", "name": "ce2-slo", "type": "ovn-k8s-cni-overlay", "topology": "localnet", "netAttachDefName": "f5-ce/ce2-slo", "mtu": 1500, "vlanID": 3052, "ipam": {} } Internal Network (ce2-sli): Internal Network (ce2-sli): Provides an isolated Layer 2 network for internal communication. By setting the topology to "layer2", this network operates as an internal overlay network that is not directly connected to the physical network infrastructure. The mtu is set to 1400 bytes to accommodate any overhead introduced by encapsulation protocols used in the internal network overlay. apiVersion: k8s.cni.cncf.io/v1 kind: NetworkAttachmentDefinition metadata: name: ce2-sli namespace: f5-ce spec: config: | { "cniVersion": "0.4.0", "name": "ce2-sli", "type": "ovn-k8s-cni-overlay", "topology": "layer2", "netAttachDefName": "f5-ce/ce2-sli", "mtu": 1400, "ipam": {} } VirtualMachine Configuration Configuring the virtual machine involves preparing the image, creating cloud-init user data, and defining the VirtualMachine resource. Image Preparation Obtain XC CE Image: Download the qcow2 image from the F5 Distributed Cloud Console. Generate Node Token: Acquire a one-time node token for node registration. Cloud-Init User Data Create a user-data configuration containing the node token and network settings: #cloud-config write_files: - path: /etc/vpm/user_data content: | token: <your-node-token> slo_ip: <IP>/<prefix> slo_gateway: <Gateway IP> slo_dns: <DNS IP> owner: root permissions: '0644' Replace placeholders with actual network configurations. This file automates the VM's initial setup and registration. VirtualMachine Resource Definition Define the VirtualMachine resource, specifying CPU, memory, disks, network interfaces, and cloud-init configurations. Resources: Allocate sufficient CPU and memory. Disks: Reference the DataVolume containing the XC CE image. Interfaces: Attach NADs for network connectivity. Cloud-Init: Embed the user data for automatic configuration. Conclusion Deploying F5 Distributed Cloud CE in OpenShift Virtualization enables organizations to leverage advanced networking and security features within their existing Kubernetes infrastructure. This integration facilitates a more secure, efficient, and scalable environment for modern applications. For detailed deployment instructions and configuration examples, please refer to the attached PDF guide. Related Articles: BIG-IP VE in Red Hat OpenShift Virtualization VMware to Red Hat OpenShift Virtualization Migration OpenShift Virtualization599Views1like0CommentsVIPTest: Rapid Application Testing for F5 Environments
VIPTest is a Python-based tool for efficiently testing multiple URLs in F5 environments, allowing quick assessment of application behavior before and after configuration changes. It supports concurrent processing, handles various URL formats, and provides detailed reports on HTTP responses, TLS versions, and connectivity status, making it useful for migrations and routine maintenance.599Views5likes2CommentsHow I did it - “Delivering Kasm Workspaces three ways”
Securing modern, containerized platforms like Kasm Workspaces requires a robust and multi-faceted approach to ensure performance, reliability, and data protection. In this edition of "How I did it" we'll see how F5 technologies can enhance the security and scalability of Kasm Workspaces deployments.299Views2likes0CommentsNeed help to understand operation between RE and CE ?
Hi all, We have installed CE site in our network and this site has established IPSEC tunnels with RE nodes. The on-prem DC site has workloads (e.g actual web application servers that are serving the client requests). I have citrix netscaler background and the Citrix Netscalers ADCs are configured with VIPs which are the frontend for the client requests coming from outside (internet), when the request land on VIPs, it goes through both source NAT and destination NAT, its source address is changed to private address according to the service where the actual application servers are configured and then sent to the actual application server after changing the destination to IP address of the server. In XC, the request will land to the cloud first because the public IP, which is assigned to us will lead the request to RE. I have few questions regarding the events that will happen from here after Will there going to be any SNAT on the request or will it send it as it is to the site? And if there is SNAT then what IP address will it be ? and will it be done by the RE or on-prem CE There has to be destination NAT. Will this destination NAT is going to be performed by the XC cloud or the request will be sent to the site and site will do the destination NAT ? When the request will land the CE it will be landed in VN local outside so this means that we have to configure the network connector between the VN Local outside and the VN in which the actual workloads are configured, what type of that VN would be ? When the request will be responded by the application server in local on-prem the site the request has to go out to the XC cloud first, it will be routed via IPSEC tunnel so this means that we have to install the network connector between the Virtual network where the workloads are present and site local outside, do we have to install the default route in application VN ? Is there any document, post or article that actually help me to understand the procedure (frankly I read a lot of F5 documents but couldn’t able to find the answers200Views0likes10CommentsSeamless Application Migration to OpenShift Virtualization with F5 Distributed Cloud
As organizations endeavor to modernize their infrastructure, migrating applications to advanced virtualization platforms like Red Hat OpenShift Virtualization becomes a strategic imperative. However, they often encounter challenges such as minimizing downtime, maintaining seamless connectivity, ensuring consistent security, and reducing operational complexity. Addressing these challenges is crucial for a successful migration. This article explores how F5 Distributed Cloud (F5 XC), in collaboration with Red Hat's Migration Toolkit for Virtualization (MTV), provides a robust solution to facilitate a smooth, secure, and efficient migration to OpenShift Virtualization. The Joint Solution: F5 XC CE and Red Hat MTV Building upon our previous work on deploying F5 Distributed Cloud Customer Edge (XC CE) in Red Hat OpenShift Virtualization, we delve into the next phase of our joint solution with Red Hat. By leveraging F5 XC CE in both VMware and OpenShift environments, alongside Red Hat’s MTV, organizations can achieve a seamless migration of virtual machines (VMs) from VMware NSX to OpenShift Virtualization. This integration not only streamlines the migration process but also ensures continuous application performance and security throughout the transition. Key Components: Red Hat Migration Toolkit for Virtualization (MTV): Facilitates the migration of VMs from VMware NSX to OpenShift Virtualization, an add-on to OpenShift Container Platform F5 Distributed Cloud Customer Edge (XC CE) in VMware: Manages and secures application traffic within the existing VMware NSX environment. F5 XC CE in OpenShift: Ensures consistent load balancing and security in the new OpenShift Virtualization environment. Demonstration Architecture To illustrate the effectiveness of this joint solution, let’s delve into the Demo Architecture employed in our demo: The architecture leverages F5 XC CE in both environments to provide a unified and secure load balancing mechanism. Red Hat MTV acts as the migration engine, seamlessly transferring VMs while F5 XC CE manages traffic distribution to ensure zero downtime and maintain application availability and security. Benefits of the Joint Solution 1. Seamless Migration: Minimal Downtime: The phased migration approach ensures that applications remain available to users throughout the process. IP Preservation: Maintaining the same IP addresses reduces the complexity of network reconfiguration and minimizes potential disruptions. 2. Enhanced Security: Consistent Policies: Security measures such as Web Application Firewalls (WAF), bot detection, and DoS protection are maintained across both environments. Centralized Management: F5 XC CE provides a unified interface for managing security policies, ensuring robust protection during and after migration. 3. Operational Efficiency: Unified Platform: Consolidating legacy and cloud-native workloads onto OpenShift Virtualization simplifies management and enhances operational workflows. Scalability: Leveraging Kubernetes and OpenShift’s orchestration capabilities allows for greater scalability and flexibility in application deployment. 4. Improved User Experience: Continuous Availability: Users experience uninterrupted access to applications, unaware of the backend migration activities. Performance Optimization: Intelligent load balancing ensures optimal application performance by efficiently distributing traffic across environments. Watch the Demo Video To see this joint solution in action, watch our detailed demo video on the F5 DevCentral YouTube channel. The video walks you through the migration process, showcasing how F5 XC CE and Red Hat MTV work together to facilitate a smooth and secure transition from VMware NSX to OpenShift Virtualization. Conclusion Migrating virtual machines (VMs) from VMware NSX to OpenShift Virtualization is a significant step towards modernizing your infrastructure. With the combined capabilities of F5 Distributed Cloud Customer Edge and Red Hat’s Migration Toolkit for Virtualization, organizations can achieve this migration with confidence, ensuring minimal disruption, enhanced security, and improved operational efficiency. Related Articles: Deploying F5 Distributed Cloud Customer Edge in Red Hat OpenShift Virtualization BIG-IP VE in Red Hat OpenShift Virtualization VMware to Red Hat OpenShift Virtualization Migration OpenShift Virtualization199Views1like0CommentsHow to use F5 Distributed Cloud for API Discovery
In today's digital landscape, APIs are crucial for integrating diverse applications and services by enabling seamless communication and data sharing between systems. API discovery involves finding, exploring, and assessing APIs for their suitability in applications, considering their varied sources and functionalities. F5 Distributed provides multiple architectures that make it ridiculously easy to discover APIs.199Views1like1Comment
