F5 Per-App AS3 Part 1 How Share Tenant specific object

There are many references for configuring and using shared objects under the Common partition but what if each partition/tenant is customer specific and each customers wants an irule that can be shared between their apps?

Code version:

The code was tested on 17.1.5.3

AS3: 3.55

For testing F5 AS3 you can use combination of Postman as Visual Studio has option to post AS3 declarations but not Per-App specific as that will be needed for executing my code. Still I recommend using Visual Studio for general AS3 or Fast Templates and you can use the reference links for how to use Visual Studio F5 extensions and maybe F5 will update the extension in the future to work for Per-App AS3 with options for adding tenant and as variables 🤔 For FAST nice example is at

https://github.com/Nikoolayy1/fast-template-examples

The same way the /Shared objects can be configured under /Common can be done under a specific tenant and this is really useful if Per-App AS3 is enabled as each AS3 app will use separate declaration and all of them can use a customer iRule defined under /<Tenant>/Shared.

References for AS3 Declarative API:

https://www.youtube.com/watch?v=rrjrcnwAe1g&t=433s

AS3 Foundations: Beyond Imperatives - What the Heck is AS3? | DevCentral

https://www.youtube.com/watch?v=OHSBpOtQg_0&list=PLrn3yqXftAPUPdSP_kbCX6BDicVprsnfI

Per-App AS3 is enabled by default for the AS3 3.50.x and above but if needed enable it.

POST Endpoint: /mgmt/shared/appsvcs/settings

{
"perAppDeploymentAllowed": true
}

POST Endpoint for Creating the Tenant and the Shared irule that is base64 endpoint: /mgmt/shared/appsvcs/declare

{
    "schemaVersion": "3.45.0",
    "Shared": {
        "class": "Application",
        "template": "shared",
        "test": {
            "class": "iRule",
            "remark": "yes",
            "iRule": {
                "base64": "d2hlbiBIVFRQX1JFUVVFU1Qgew0KICAgSFRUUDo6cmVzcG9uZCAyMDAgY29udGVudCB7DQogICAgICA8aHRtbD4NCiAgICAgICAgIDxoZWFkPg0KICAgICAgICAgICAgPHRpdGxlPkFwb2xvZ3kgUGFnZTwvdGl0bGU+DQogICAgICAgICA8L2hlYWQ+DQogICAgICAgICA8Ym9keT4NCiAgICAgICAgICAgIFdlIGFyZSBzb3JyeSwgYnV0IHRoZSBzaXRlIHlvdSBhcmUgbG9va2luZyBmb3IgaXMgdGVtcG9yYXJpbHkgb3V0IG9mIHNlcnZpY2U8YnI+DQogICAgICAgICAgICBJZiB5b3UgZmVlbCB5b3UgaGF2ZSByZWFjaGVkIHRoaXMgcGFnZSBpbiBlcnJvciwgcGxlYXNlIHRyeSBhZ2Fpbi4NCiAgICAgICAgIDwvYm9keT4NCiAgICAgIDwvaHRtbD4NCiAgIH0NCn0="
            }
        }
    }
}

POST Endpoint for sending Per-App AP that references the Tenant shared iRule I: /mgmt/shared/appsvcs/declare/Example/applications

{
    "schemaVersion": "3.45.0",
    "A1": {
        "class": "Application",
        "service": {
            "class": "Service_HTTP",
            "virtualAddresses": [
                "10.0.1.10"
            ],
            "pool": "web_pool",
            "iRules": [
                {
                    "use": "/Test/Shared/test"
                },
                "insert_xff"
            ]
        },
        "web_pool": {
            "class": "Pool",
            "monitors": [
                "http"
            ],
            "members": [
                {
                    "servicePort": 80,
                    "serverAddresses": [
                        "192.0.1.10",
                        "192.0.1.12"
                    ]
                }
            ]
        },
        "insert_xff": {
            "class": "iRule",
            "iRule": "when HTTP_REQUEST { HTTP::header insert X-Forwarded-For [IP::client_addr] }"
        }
    }
}

Github link:

Editing AS3-Per-App-Shared-Tenant-Objects/README.md at main · Nikoolayy1/AS3-Per-App-Shared-Tenant-Objects

Note!

To see the Tenant config use GET Endpoint /mgmt/shared/appsvcs/declare/Example or for the app /mgmt/shared/appsvcs/declare/Example/A1

For only the Tenant shared config use GET /mgmt/shared/appsvcs/declare/Example/applications/Shared

By placing the pools in the /Shared under the Tenant all Per-AS3 declarations for Tenant can use the pool like for the iRule example I showed and also the pools can share the node IP addresses like the "shareNodes" option but only for the tenant.

https://my.f5.com/manage/s/article/K88250015

Published Jan 17, 2026

Version 1.0
