Forward ActiveSync Requests if user is member of BLABLA

Hi



I'm trying to deploy an APM policy for Exchange ifrastructure. Here is the hard part for my knowledge. I have to check user's membership and then forward them to "deny||allow" branch. Since, ActiveSync requests doesn't follow my policy design I could not detect membership. By the way, I 've used recent iApp to create this Access Policy. It works nice but I need to implement "the hard part"



How could I go further?



application delivery
BIG-IP Access Policy Manager (APM)

4 Replies

  • Cory_O's avatar
    Cory_O
    Icon for Cirrostratus rankCirrostratus
    Mar 17, 2016

    What I did was add an LDAP Query (or AD Query if you like).

    At first, I pulled the memberOf attribute and created a Deny Branch Rule with the following syntax:

    expr { [string tolower [mcget {session.server.landinguri}]] contains "/microsoft-server-activesync" && [string match -nocase *CN=YOURGROUPHERE,OU=GRP-WorkGRP,OU=USA-Groups,OU=USA,DC=na,DC=yourdomain,DC=com* [mcget {session.ldap.last.attr.memberOf}]] == 0 }

    Then I create an Allow Branch at the bottom that sets the SSO and moves forward.

    The problem with the above method is that the LDAP Query pulls a literal group membership. If the user is a member of a group that is NESTED within the group mentioned in the Branch Rule above, it will not be considered. With that said, I moved on to setting an AD Attribute for those I wanted to allow or deny access.

    Here's the new Deny branch I created:

    expr { [mcget {session.ldap.last.attr.extensionAttribute15}] == "External-Access-Restricted" }
    (Change the attribute and return string to whatever you'd like to use)

    The second has worked very well for me so far, but feel free to experiment with either!

    -Cory

  • Stanislas_Piro2's avatar
    Stanislas_Piro2
    Icon for Cumulonimbus rankCumulonimbus
    Mar 21, 2016

    Hi,

    If you need to validate only one group membership with nested group, you can use the following filter in LDAP query:

    (&(sAMAccountName=%{session.logon.last.username})(memberof:1.2.840.113556.1.4.1941:=CN=YOURGROUPHERE,OU=GRP-WorkGRP,OU=USA-Groups,OU=USA,DC=na,DC=yourdomain,DC=com)(sAMAccountType=805306368))

    This filter will request to AD if the user is member of the group, including nested groups.
