asm irule to unblock upon violation based on type
- Apr 04, 2018
Solved! YESSS!
First clue: https://devcentral.f5.com/Wiki/iRules.ASM__violation_data.ashx
Position Field Description **0 Violation** string that contains list of comma separated violations, see below the rquest side and response side violations for value options 1 support_id Unique id given for a transaction 2 web_application ASM Web application name 3 Severity it will be the most critical severity of all the transaction violations, possible values: Emergency, Alert, Critical, Error, Warning, Notice and Informational 4 source_ip Client IP. (in case trust xff option is enabled on the policy, this will be the xff ip **5 attack_type** string that contains list of comma separated attack types, see below for value options 6 request_status Can be “blocked” or “alarmed”
Second clue: ATTACK_TYPE_INFORMATION_LEAKAGEInformation Leakage
So I am browsing the wrong hole which is 0 for matches instead of the correct one which is 5.
Third clue: Note: Starting version 11.5.0 this command is replaced by the commands ASM::violation, ASM::support_id, ASM::severity and ASM::client_ip which have more convenient syntax and enhanced options. It is kept for backward compatibility.
Also had to enable compatibility mode for Trigger iRule upon ASM event.
Solved! YESSS!
First clue: https://devcentral.f5.com/Wiki/iRules.ASM__violation_data.ashx
Position Field Description
**0 Violation** string that contains list of comma separated violations, see below the rquest side and response side violations for value options
1 support_id Unique id given for a transaction
2 web_application ASM Web application name
3 Severity it will be the most critical severity of all the transaction violations, possible values: Emergency, Alert, Critical, Error, Warning, Notice and Informational
4 source_ip Client IP. (in case trust xff option is enabled on the policy, this will be the xff ip
**5 attack_type** string that contains list of comma separated attack types, see below for value options
6 request_status Can be “blocked” or “alarmed”
Second clue: ATTACK_TYPE_INFORMATION_LEAKAGEInformation Leakage
So I am browsing the wrong hole which is 0 for matches instead of the correct one which is 5.
Third clue: Note: Starting version 11.5.0 this command is replaced by the commands ASM::violation, ASM::support_id, ASM::severity and ASM::client_ip which have more convenient syntax and enhanced options. It is kept for backward compatibility.
Also had to enable compatibility mode for Trigger iRule upon ASM event.
