Concept of F5 Device DoS and DoS profiles
Dear Reader, I´m about to write a series of DDoS articles, which will hopefully help you to better understand how F5 DDoS works and how to configure it. I plan to release them in a more or less regular frequency. Feel free to send me your feedback and let me know which topics are relevant for you and should get covered. This first article is intended to give an explanation of the BIG-IP Device DOS and Per Service-DOS protection (DOS profile). It covers the concepts of both approaches and explains in high level the threshold modes “Fully manual”, “Fully Automatic” and “Multiplier Based Mitigation” including the principles of stress measurement. In later articles I will describe this threshold modes in more detail. In the end of the article you will also find an explanation of the physical and logical data path of the BIG-IP. Device DOS with static DoS vectors The primary goal of “Device DOS” is to protect the BIG-IP itself. BIG-IP has to deal with all packets arriving on the device, regardless of an existing listener (Virtual Server (VS)/ Protected Object (PO)), connection entry, NAT entry or whatever. As soon as a packet hits the BIG-IP it´s CPU has basically to deal with it. Picking up each and every packet consumes CPU cycles, especially under heavy DOS conditions. The more operations each packet needs, depending on configurations, the higher the CPU load gets, because it consumes more CPU cycles. The earlier BIG-IP can drop a packet (if the packet needs to get dropped) the better it is for the CPU load. If the drop process is done in hardware (FPGA), the packet gets dropped before it consumes CPU cycles. Using static DOS vectors helps to lower the number of packets hitting the CPU when under DoS. If the number of packets is above a certain threshold (usually when a flood happens), BIG-IP rate-limits for that specific vector, which keeps the CPU available, because it sees less packets. Figure 1: Principle of Attack mitigation with static DoS vectors The downside with this approach is that the BIG-IP cannot differentiate between "legitimate" and "attacking" packets, when using static DOS rate-limit. BIG-IP (FPGA) just drops on the predicates it gets from the static DOS vector. Predicates are attributes of a packet like protocol “TCP” or “flag” set “ACK”. -Keep in mind, when BIG-IP runs stateful, "bad" packets will get dropped in software anyway by the operating system (TMOS), when it identifies them as not belonging to an existing connection or as invalid/broken (for example bad CRC checksum). This is of course different for SYN packets, because they create connection entries. This is where SYN-Cookies play an important role under DoS conditions and will be explained in a later article. I usually recommend running Behavioral DoS mitigation in conjunction with static DoS vectors. It is way more precise and able to filter out only the attack traffic, but I will discuss this in more detail also in one of the following articles. Manual threshold vs. Fully Automatic Before I start to explain the “per service DoS protection” (DoS profiles), I would like to give you a brief overview of some Threshold modes you can use per DoS vector. There are different ways to set thresholds to activate the detection and rate-limiting on a DOS vector. The operator can do it manual by using the option “Fully Manual” and then fine tune the pre-configured values on the DOS vectors, which can be challenging, because beside doing it all manually it´s mostly difficult to know the thresholds, especially because they are usually related to the day and time of the week. Figure 2: Example of a manual DoS vector configuration That’s why most of the vectors have the option "Fully Automatic" available. It means BIG-IP will learn from the history and “knows” how many packets it usually “sees” at that specific time for the specific vector. This is called the baselining and calculates the detection threshold. Figure 3: Threshold Modes As soon as a flood hits the BIG-IP and crosses the detection threshold for a vector, BIG-IP detects it as an attack for that vector, which basically means it identifies it as an anomaly. However, it does not start to mitigate (drop). This will only happen as soon as a TMM load (CPU load) is also above a certain utilization (Mitigation sensitivity: Low: 78%, Medium 68%, High: 51%). If both conditions (packet rate and TMM/CPU load is too high) are true, the mitigation starts and lowers (rate-limit) the number of packets for this vector going into the BIG-IP for the specific TMM. That means dropping packets by the DOS feature will only happen if necessary, in order to protect the BIG-IP CPU. This is a dynamic process which drops more packets when the attack becomes more aggressive and less when the attack becomes less aggressive. For TCP traffic keep in mind the “invalid” traffic will not get forwarded anyway, which is a strong benefit of running the device stateful. When a DOS vector is hardware supported then FPGAs drop the packets basically at the switch level of the BIG-IP. If it’s not hardware supported, then the packet is dropped at a very early stage of the life cycle of a packet “inside” a BIG-IP. Device DOS counts ALL packets going to the BIG-IP. It doesn´t matter if they have a destination behind the BIG-IP, or when it is the BIG-IP itself. BecauseDevice DOSis to protect the BIG-IP,the thresholdsyou can configure in the “manual configuration” mode on the DOS vectorsare per TMM! This means you configure the maximum number of packets one TMM can handle. Very often operators want to set an overall threshold of let’s say 10k, then they need to divide this limit by the number of TMMs.An Exception is the Sweep and Flood vector. Here the threshold is per BIG-IP and not per TMM. DOS profile for protected Objects Now let’s talk about the “per Service DoS Protection (DoS profile)”. The goal is to protect the service which runs behind the BIG-IP. Important to know, when BIG-IP runs stateful, the service is already protected by the state of BIG-IP (true for TCP traffic). That means a randomized ACK flood for example will never hit the service. On stateless traffic (UDP/ICMP) it is different, here the BIG-IP simply forward packets.Fully Automatic used on a DoS profile discovers thehealth of the service, which works well if its TCP or DNS traffic. (This is done by evaluating the TCP behavior like Window Size, Retransmission, Congestions, or counting DNS requests vs. responses, ....). If the detection rate for that service is crossed (anomaly detected) and stress on the service is identified, the mitigation starts. Again, keep in mind for TCP this will only happen for “legitimate” traffic, because out of the state traffic will never reach the service. It is already protected by the BIG-IP being configured state-full. An example could be a HTTP flood.My recommendation:If you have the option to configureL7 BaDOS(Behavioral DOS running on DHD/A-WAF), then go with that one. It gives much better results and better mitigation options on HTTP floods then just L3/4 DOS, because it does also operate on L7. Please also do thennot configureTCP DOS for “Push Flood”, "bad ACK Flood" and “SYN Flood”, on that DOS profile, except you use a TMOS version newer than 14.1. For other TCP services like POP3, SMTP, LDAP … you can always go with the L3/4 DOS vectors. Since TMOS version 15.0 L7 BaDOS and L3/4 DOS vectors work in conjunction. Stateless traffic (UDP/ICMP) For UDP traffic I would like to separate UDP into DNS traffic and non-DNS-UDP traffic. DNS is a very good example where the health detection mechanism works great. This is done by measuring the ratio of requests vs. responses. For example, if BIG-IP sees 100k queries/sec going to the DNS server and the server sends back 100k answers/sec, the server shows it can handle the load. If it sees 200k queries/sec going to the server and the server sends back only 150k queries/sec, then it is a good indication of that the server cannot handle the load. In that case the BIG-IP would start to rate-limit, when the current rate is also above the detection rate (The rate BIG-IP expects based on the history rates). The 'Device UDP' vector gives you the option to exclude UDP traffic on specific ports from the UDP vector (packet counting). For example, when you exclude port 53 and UDP traffic hits that port, then it will not count into the UDP counter. In that case you would handle the DNS traffic with the DNS vectors. Figure 4 : UDP Port exclusion Here you see an example for port 53 (DNS), 5060 (SIP), 123 (NTP) Auto Detection / Multiplier Based Mitigation If the traffic is non-DNS-UDP traffic or ICMP traffic the stress measurement does not work very accurate, so I recommend going with the“multiplier option” on the DOS profile. Here BIG-IP does the baselining (calculating the detection rate) similar to “fully automatic” mode, except it will kick in (rate-limit) if it sees more than the defined multiplication for the specific vector, regardless of the CPU load. For example, when the calculated detection rate is 250k packets/sec and the multiplication is set to 500 (which means 5 times), then the mitigation rate would be 250k x 5 = 1.250.000 packets/sec. The multiplier feature gives the nice option to configure a threshold based on the multiplication of an expected rate. Figure 5 : Multiplier based mitigation On aDOS profilethethreshold configuration is per service (all packets targeted to the protected service), which actually means on that BIG-IP and NOT per TMM like on the Device level. Here the goal is to set how many packets are allowed to pass the BIG-IP and reach the service. The distribution of these thresholds to the TMMs is done in a dynamic way: Every TMM gets a percentage of the configured threshold, based on the EPS (Events Per Second, which is in this context Packets Per Second) for the specific vector the system has seen in the second before on this TMM. This mechanism protects against hash type of attacks. Physical and logical data path There is aphysical and logical traffic pathin BIG-IP. When a packet gets dropped via a DOS profile on a VS/PO, then BIG-IP will not see it on the device level counter anymore. If the threshold on the device level is reached, the packet gets dropped by the device level and will not get to the DOS profile. So, the physical path is device first and then comes the VS/PO, but the logical path is VS/PO first and then device. That means, when a packet arrives on the device level (physical first), that counter gets incremented. If the threshold is not reached, the packet goes to the VS/PO (DOS profile) level. If the threshold is reached here, then the packet gets dropped and the counter for the device DOS vector decremented. If the packet does not get dropped, then the packet counts into both counters (Device/VS). This means that the VS/PO thresholds should always set lower than device thresholds (remember on Device level you set the thresholds per TMM!). The device threshold should be the maximum the BIG-IP (TMM) can handle overall. It is important to note that mitigation in manual mode are “hard” numbers and do not take into account the stress on the service. In “Fully Automatic” mode on the VS/PO level, mitigation kicks in when the detection threshold is reached AND the stress on the service is too high. Now let’s assume a protected TCP service behind the BIG-IP gets attacked by a TCP attack like a randomized Push/ACK food. Because of the high packet rate hitting that vector on the attached DOS profile for that PO, it will go into 'detect mode'. But because it is a TCP flood and BIG-IP is configured to run state-full, the attack packets will never reach the service behind the BIG-IP and therefore the stress on that service will never go high in this case. The flood is then handled by the session state (CPU) of the BIG-IP until this gets too much under pressure and then the Device DOS will kick in “upfront” and mitigate the flood. If you use the “multiplication” option, then the mitigation kicks in when the packet detection rate + multiplication is reached. This can happen on the VS/PO level and/or on the Device level, because it is independent of stress. “Fully automatic” will not work properly with asymmetric traffic for VS/PO, because here BIG-IP cannot identify if the service is under stress due to the fact that BIG-IP will only see half of the traffic. -Either request or response depending on where it is initiated. For deployments with asymmetric traffic I recommend using the manual or “multiplier option”, on VS/PO configurations. The “Multiplier option” keeps it dynamic in regard to the calculated detection and mitigation rate based on the history. “Fully Automatic” works with Asymmetric traffic on Device DOS, because it measures the CPU (TMM) stress of the BIG-IP itself. Of course, when you run asymmetric traffic, BIG-IP can´t be state-full. I recommend to always start first with the Device DOS configuration to protect the BIG-IP itself against DOS floods and then to focus on the DOS protection for the services behind the BIG-IP. On Device DOS you will probably mostly use “Fully Manual” and “Fully Automatic” threshold modes. To protect services, you will mostly go with “Fully Manual” and “Fully Automatic” or “Auto Detection/ Multiplier based mitigation”. In one of the next articles I will describe in more detail when to use what and why. As mentioned before, additional to the static DoS vectors I recommend enabling Behavioral DOS, which is way smarter than the static DOS vectors and can filter out specifically only the attack traffic which tremendously decrease the chance of false positives. You can enable it like the static DoS vectors on Device- an on VS/PO level. But this topic will be covered in another article as well. With that said I would like to finish my first article. Let me know your feedback. Thank you, sVen MuellerExplanation of F5 DDoS threshold modes
Der Reader, In my article “Concept of Device DOS and DOS profile”, I recommended to use the “Fully Automatic” or “Multiplier” based configuration option for some DOS vectors. In this article I would like to explain how these threshold modes work and what is happening behind the scene. When you configure a DOS vector you have the option to choose between different threshold modes: “Fully Automatic”, “Auto Detection / Multiplier Based”, “Manual Detection / Auto Mitigation” and “Fully Manual”. Figure 1: Threshold Modes The two options I normally use on many vectors are “Fully Automatic” and “Auto Detection / Multiplier Based”. But what are these two options do for me? To manually set thresholds is for some vectors not an easy task. I mean who really knows how many PUSH/ACK packets/sec for example are usually hitting the device or a specific service? And when I have an idea about a value, should this be a static value? Or should I better take the maximum value I have seen so far? And how many packets per second should I put on top to make sure the system is not kicking in too early? When should I adjust it? Do I have increasing traffic? Fully Automatic In reality, the rate changes constantly and most likely during the day I will have more PUSH/ACK packets/sec then during the night. What happens when there is a campaign or an event like “Black Friday” and way more users are visiting the webpage then usually? During these high traffic events, my suggested thresholds might be no longer correct which could lead to “good” traffic getting dropped. All this should be taken into consideration when setting a threshold and it ends up being very difficult to do manually. It´s better to make the machine doing it for you and this is what “Fully Automatic” is about. Figure 2: Expected EPS As soon as you use this option, it leverages from the learning it has done since traffic is passing through the BIG-IP, or since you have enforced the relearning, which resets everything learned so far and starts from new. The system continuously calculates the expected rates for all the vectors based on the historic rates of traffic. It takes the information up to one year and calculates them with different weights in order to know which packets rate should be expected at that time and day for that specific vector in the specific context (Device, Virtual Server/Protected Object). The system then calculates a padding on top of this expected rate. This rate is called Detection Rate and is dependent on the “threshold sensitivity” you have configured: Low Sensitivity means 66% padding Medium Sensitivity means 40% padding High Sensitivity means 0% padding Figure 3: Detection EPS As soon as the current rate is above the detection value, the BIG-IP will show the message “Attack detected”, which actually means anomaly detected, because it sees more packets of that specific vector then expected + the padding (detection_rate). But DoS mitigation will not start at that point! Figure 4: Current EPS Keep in mind, when you run the BIG-IP in stateful mode it will drop 'out of state' packets anyway. This has nothing to do with DoS functionalities. But what happens when there is a serious flood and the BIG-IP CPU gets high because of the massive number of packets it has to deal with? This is when the second part of the “Fully Automatic” approach comes into the game. Again, depending on your threshold sensitivity the DOS mitigation starts as soon as a certain level of stress is detected on the CPU of the BIG-IP. Figure 5: Mitigation Threshold Low Sensitivity means 78,3% TMM load Medium Sensitivity means 68,3% TMM load High Sensitivity means 51,6% TMM load Note, that the mitigation is per TMM and therefore the stress and rate per TMM is relevant. When the traffic rate for that vector is above the detection rate and the CPU of the BIG-IP (Device DOS) is “too” busy, the mitigation kicks in and will rate limit on that specific vector. When a DOS vector is hardware supported, FPGAs drop the packets at the switch level of the BIG-IP. If that DOS vector is not hardware supported, then the packet is dropped at a very early stage of the life cycle of a packet inside a BIG-IP. The rate at which are packets dropped is dynamic (mitigation rate), depending on the incoming number of packets for that vector and the CPU (TMM) stress of the BIG-IP. This allows the stress of the CPU to go down as it has to deal with less packets. Once the incoming rate is again below the detection rate, the system declares the attack as ended. Note: When an attack is detected, the packet rate during that time will not go into the calculation of expected rates for the future. This ensures that the BIG-IP will not learn from attack traffic skewing the automatic thresholds. All traffic rates below the detection (or below the floor value, when configured) rate modify the expected rate for the future and the BIG-IP will adjust the detection rate automatically. For most of the vectors you can configure a floor and ceiling value. Floor means that as long as the traffic value is below that threshold, the mitigation for that vector will never kick in. Even when the CPU is at 100%. Ceiling means that mitigation always kicks in at that rate, even when the CPU is idle. With these two values the dynamic and automatic process is done between floor and ceiling. Mitigation only gets executed when the rate is above the rate of the Floor EPS and Detection EPS AND stress on the particular context is measured. Figure 6: Floor and Ceiling EPS What is the difference when you use “Fully Automatic” on Device level compared to VS/PO (DOS profile) level? Everything is the same, except that on VS or Protected Object (PO) level the relevant stress is NOT the BIG-IP device stress, it is the stress of the service you are protecting (web-, DNS, IMAP-server, network, ...). BIG-IP can measure the stress of the service by measuring TCP attributes like retransmission, window size, congestion, etc. This gives a good indication on how busy a service is. This works very well for request/response protocols like TCP, HTTP, DNS. I recommend using this, when the Protected Object is a single service and not a “wildcard” Protected Object covering for example a network or service range. When the Protected Object is a “wildcard” service and/or a UDP service (except DNS), I recommend using “Auto Detection / Multiplier Option”. It works in the same way as the “Fully Automatic” from the learning perspective, but the mitigation condition is not stress, it is the multiplication of the detection rate. For example, the detection rate for a specific vector is calculated to be 100k packets/sec. By default, the multiplication rate is “500”, which means 5x. Therefore, the mitigation rate is calculated to 500k packets/sec. If that particular vector has more than 500k packets/sec those packets would be dropped. The multiplication rate can also be individually configured. Like in the screenshot, where it is set to 8x (800). Figure 7: Auto Detection / Multiplier Based Mitigation The benefit of this mode is that the BIG-IP will automatically learn the baseline for that vector and will only start to mitigate based on a large spike. The mitigation rate is always a multiplication of the detection rate, which is 5x by default but is configurable. When should I use “Fully Manual”? When you want to rate-limit a specific vector to a certain number of packets/sec, then “Fully Manual” is the right choice. Very good examples for that type of vector are the “Bad Header” vector types. These type of packets will never get forwarded by the BIG-IP so dropping them by a DoS vector saves the CPU, which is beneficial under DoS conditions. In the screenshot below is a vector configured as “Fully Manual”. Next I’ll describe what each of the options means. Figure 8: Fully Manual Detection Threshold EPS configures the packet rate/sec (pps) when you will get a log messages (NO mitigation!). Detection Threshold % compares the current pps rate for that vector with the multiplication of the configured percentage (in this example 5 for 500%) with the 1-minute average rate. If the current rate is higher, then you will get a log message. Mitigation Threshold EPS rate limits to that configured value (mitigation). I recommend setting the threshold (Mitigation Threshold EPS) to something relatively low like ‘10’ or ‘100’ on ‘Bad Header’ type of vectors. You can also set it also to ‘0’, which means all packets hitting this vector will get dropped by the DoS function which usually is done in hardware (FPGA). With the ‘Detection Threshold EPS’ you set the rate at which you want to get a log messages for that vector. If you do it this way, then you get a warning message like this one to inform you about the logging behavior: Warning generated: DOS attack data (bad-tcp-flags-all-set): Since drop limit is less than detection limit, packets dropped below the detection limit rate will not be logged. Another use-case for “Fully Manual” is when you know the maximum number of these packets the service can handle. But here my recommendation is to still use “Fully Automatic” and set the maximum rate with the Ceiling threshold, because then the protected service will benefit from both threshold options. Important: Please keep in mind, when you set manual thresholds for Device DoS the thresholds are to protect each TMM. Therefore the value you set is per TMM! An exception to this is the Sweep and Flood vector where the threshold is per BIG-IP/service and not per TMM like on DoS profiles. When using manual thresholds for aDOS profileof a Protected Object thethreshold configuration is per service (all packets targeted to the protected service) NOT per TMM like on the Device level. Here the goal is to set how many packets are allowed to pass the BIG-IP and reach the service. The distribution of these thresholds to the TMMs is done in a dynamic way: Every TMM gets a percentage of the configured threshold, based on the EPS (Events Per Second, which is in this context Packets Per Second) for the specific vector the system has seen in the second before on this TMM. This mechanism protects against hash type of attacks. Ok, I hope this article gives you a better understanding on how ‘Fully Manual’, ‘Fully Automatic’ and ‘Auto Detection / Multiplier Based Mitigation’ works. They are important concepts to understand, especially when they work in conjunction with stress measurement. This means the BIG-IP will only kick in with the DoS mitigation when the protected object (BIG-IP or the service behind the BIG-IP) is under stress. -Why risk false positives, when not necessary? With my next article I will demonstrate you how Device DoS and the DoS profiles work together andhow the stateful concept cooperates with the DoS mitigation. I will show you some DoS commands to test it and also commands to get details from the BIG-IP via CLI. Thank you, sVen MuellerF5 Distributed Cloud - Regional Decryption with Virtual Sites
