Configuring an Application for Smart Card Authentication and Forms Based SSO Using a Static Username and Password

A customer recently reached out requesting assistance providing smart card authentication to an application that does not integrate with AD or LDAP and has only a single username and password. While many of you out there may have done this in the past, I for one had not and of course I too was curious how I could make such a solution work. So with that, let's get to it.

In order to successfully deploy this solution, please configure the following prerequisites.

Local Traffic Manager licensed and provisioned
Access Policy Manager licensed and provisioned
CA certificate or a bundle of CA certs

Note: This CA cert or bundle will contain all CA certs which issued the client certificates you will be authenticating with.

OCSP IP address for certificate revocation checking

Configuring a LDAP AAA Resource

Navigate to Access > Authentication > LDAP and select Create
Name: Demo_LDAP_AAA
Server Connection: Direct
Base Port: 389
Admin DN: CN=admin,CN=Users,DC=demo,DC=lab
Leave all other settings at their defaults and select Finished

Configuring a OCSP AAA Resource

Navigate to Access > Authentication > OCSP Responder > Select Create
Name: Demo_OCSP
URL: http://OCSP_IP/ocsp
Certificate Authority File: Select the issuing CA Certificate
Leave all other settings at their defaults and select Finished

Creating a Webtop

Navigate to Access >> Webtops >> Webtop Lists: Create
From the drop down select Full for the type of Webtop you will be deploying, provide a name and select Finished.

Identify Form, Form Action and Form Parameters

In this scenario I used Firefox though your favorite browser can also be used. This data will be used to configure our SSO profile.

Lunch Firefox and browse to the application you are attempting to configure SSO for.
From the Firefox Menu bar, select Tools >> Web Developer >> Click Inspector

To make it easy to identify the form I simply clicked in the USERNAME or PASSWORD in fields in the web page and Inspector took me to that content.

Capture action: /console/j_spring_security_check
Capture method: POST
Capture input id for the username parameter
Capture input id for the password parameter

Create a Forms SSO Profile

Navigate to Access >> Single Sign-On >> Forms Based >> Click Create
Name: Demo_Web_App_Forms_SSO
User SSO Template: None
Username Source: session.sso.token.last.username
Password Source: session.sso.token.last.password
Start URI: This is URI of the application at the logon screen

Form Method: Post
Form Action: /console/j_spring_security_check
Form Parameter For User Name: username
Form Parameter For Password: password
Click Finished

Create a Portal Access Resource

Navigate to Access >> Connectivity / VPN >> Portal Access >> Portal Access List >> Click Create
Name: Demo_Web_App
Link Type: Application URI
Application URI: URI to your web application
Caption: Demo_Web_App
Click Create

After you click Create, the page will refresh and at the bottom of the screen you will then see an option to create Resource Items

Click Add
Destination: IP or Host Name of the web application
Link Type: Paths
Paths: /*
Scheme: https
SSO Configuration: Demo_Web_App_Forms_SSO
Click Finished

Create a Connectivity Profile

Navigate to Access >> Connectivity / VPN > Connectivity >> Profiles >> Click Add
Profile Name: Demo_CP
Parent Profile: connectivity
Click OK

Create Client Cert Access Policy

Navigate to Access > Profiles / Policies > Select Create
Name: Demo_cert_Auth
Profile Type: All
Profile Scope: Profile
Languages: Select your desired language and move it to Accepted Languages
Leave all other settings at their defaults and select Finished

Modify the Access Policy Using the Visual Policy Editor

From the Access > Profiles > Policies : Access Profiles (Per-Session Policies) page, select Edit from the access policy created in the previous step.

Between Start and Deny select the +
From the popup select the Authentication tab and select On_Demand Cert Auth > Add Item

You will be presented with an option to request or require a client present a client certificate. For this example, we will Require the client present a certificate.
Select Save

Following the successful branch of On Demand Cert Auth in the VPE, select +
From the Authentication tab, select OCSP Auth > Add Item
From the OCSP Responder drop down, select the OCSP AAA object created in previous steps.
Certificate Type: User
Click Save

Following the successful branch of OCSP Auth, select +
From the Assignment tab, select Variable Assign > Add Item

From the first empty Assignment, select Change
Custom Variable: session.sso.token.last.password
Select Secure from the drop down menu

Note: Unsecure or Secure specifies whether the variable is secure. A secure variable is stored in encrypted form in the session database. The value of a secure variable is not displayed in the session report, or logged by the logging agent.

Text: password
Select Finished

Under Variable Assign, select Add new entry > Change empty variable
Custom Variable: session.sso.token.last.username
Text: admin

Under Variable Assign, select Add new entry > Change empty variable
Custom Variable: session.logon.last.upn
Custom Expression:

set x509e_fields [split [mcget {session.ssl.cert.x509extension}] "\n"];  # For each element in the list:  foreach field $x509e_fields {  # If the element contains UPN:
if { $field contains "othername:UPN" } {  ## set start of UPN variable  set start [expr {[string first "<" $field] +1}]  # UPN format is   # Return the UPN, by finding the index of opening and closing brackets, then use string range to get everything between.  return [string range $field $start [expr { [string first ">" $field $start] - 1 } ] ];  } }  # Otherwise return UPN Not Found:  return "UPN-NOT-FOUND";

Select Finished > Save

Select Save

Following the fallback branch of Variable Assign, select +
From the Authentication tab, select LDAP Query > Add Item

From the Server drop down, select the LDAP AAA created in previous steps
SearchDN: CN=Users,DC=demo,DC=lab
SearchFilter: UserPrincipalName=%{session.logon.last.upn}
Fetch Groups to which the user or group below: Direct
Required Attributes: sAMAccountName
Required Attributes: memberOf

Note: sAMAccountName is not required for successful authentication as it is when performing Kerberos KCD though it can be useful to know who is logging in by name versus a long string of characters.

Navigate to the Branch Rules tab
Remove the existing Group Membership expression by selecting the X
Select Add Branch Rule
Name: LDAP Query Successful
Next to expression, select change
Agent Sel: LDAP Query
Condition: LDAP Query Passed
LDAP Query has: Passed
Select Add Expression > Finished

Click Save

Following the LDAP Query Successful branch, select +
From the Assignment tab, select SSO Credential Mapping > Add Item
SSO Token Username: mcget {session.sso.token.last.username}
SSO Token Password: mcget {session.sso.token.last.password}

Click Save
Following the SSO Credential Mapping branch select +
Select Advanced Resource Assign from the Assignment tab

Click Add new entry
Click Add/Delete

From the Portal Access tab, select the Demo_Web_App resource created in previous tasks.
From the Webtop tab, select the demo_webtop created in previous tasks.
Click Update
Click Save
From the fallback branch, select Deny
Change ending to Allow and click Save

At this point, you have a fully deployed VPE capable of supporting smart card authentication and have statically created a username and password that will be included in your HTTP Post to the web application.

Select Apply Policy

Configure SSL Client Profile

To support client certificate-based authentication, we must also create a Client SSL Profile on the BIG-IP using the steps below.
Navigate to Local Traffic > Profiles > SSL > Client > Create
Name: DemoSSLProfile
Certificate Key Chain: Place a check mark under the custom field. Click Add to select the appropriate cert/key pair.
Client Certificate: Leave it set to ignore as the APM ODCA will perform this function.
Trusted Certificate Authorities: Select the CA or CA bundle certificate
Advertised Certificate Authorities: Select the CA or CA bundle certificate

All other settings can be left at their defaults.
Click Finished

Create a Virtual Server for your Web Application

Navigate to Local Traffic >> Virtual Servers >> Click Create
Name: Demo_Web_App_VS
Destination Address: IP that users will connect to in order to access the web application
Service Port: 443
Protocol Profile (Client): f5-tcp-lan
HTTP Profile: http
SSL Profile (Client): DemoSSLProfile
SSL Profile (Server): serverssl

Source Address Translation: Automap
Rewrite Profile: rewrite_portal
Access Profile: Demo_cert_Auth
Connectivity Profile: Demo_CP

Click Finished

At this point, we have successfully configured all components required to support this use case so let's attempt access.

Validation Testing

From a browser navigate to the IP of your virtual server or the DNS name that resolves that IP
You should be prompted for user certificate

Select your user cert and Click OK
You should be presented with your Webtop

Click on the resource item and you should be redirected to that web application
If your configuration is correct, you will be logged in using the SSO credentials provided within the VPE and SSO profile.

In my first attempt I actually was not successful and received no logon error. This is likely one of 2 things, either I did not assign my SSO profile or the Start URI is incorrect. Let's validate

Validated SSO profile is assigned

Ahhh, now I see! Human error of course. I typed the Start URI incorrectly so, no there was no uri match.

After modifying the Start URI to the correct URI, I am now able to successfully login using the SSO configuration in this guide.

I am by no means saying this will be a common configuration though it is a use case that I have seen in the field more than once. As always, if it helps at least one of you out there it was well worth it. Until next time.
