2303 TopicsScality RING and F5 BIG-IP: High-Performance S3 Object Storage
The load balancing of F5 BIG-IP, both locally within a site as well as for global traffic steering to an optimal site around large geographies, works effectively with Scality RING, a modern and massively scalable object storage solution. The RING architecture takes an innovative “bring-your-own Linux” approach to turning highly performant servers, equipped with ample disks, into a resilient, durable storage solution. The BIG-IP can scale in lock step with offered S3 access loads, for use cases like AI data delivery for model training as an example, avoiding any single RING node from being a hot spot, with pioneering load balancing algorithms like “Least Connections” or “Fastest”, to name just a couple. From a global server load balancing perspective, BIG-IP DNS can apply similar advanced logic, for instance, steering S3 traffic to the optimal RING site, taking into consideration the geographic locale of the traffic source or leveraging on-going latency measurements from these traffic source sites. Scality RING – High Capacity and Durability for Today’s Object Storage The Scality solution is well known for the ability to grow the capacity of an enterprise’s storage needs with agility; simply license the usable storage needed today and upgrade on an as-needed basis as business warrants. RING supports both object and file storage; however, the focus of this investigation is object. Industry drivers of object storage growth include its prevalence in AI model training, specifically for content accrual, which will in-turn feed GPUs, as well as data lakehouse implementations. There is an extremely long-tailed distribution of other use cases, such as video clip retention in the media and entertainment industry, medical imaging repositories, updates to traditional uses like NAS offload to S3 and the evolution of enterprise storage backups. At the very minimum, a 3-node site, with 200 TB of storage, serves as a starting point for a RING implementation. The underlying servers typically run RHEL 9 or Rocky Linux, running upon x86 or AMD architectures, and a representative server would offer disk bays, front or back, with loaded disks totally anywhere from 10 to dozens of disk units. Generally, S3 objects are stored upon spinning hard disk drives (HDD) while the corresponding metadata warrants inclusion of a subset of flash drives in a typical Scality deployment. A representative diagram of BIG-IP in support of a single RING site would be as follows. One of the known attributes of a well-engineered RING solution is 100 percent data availability. In industry terms, this is an RPO (recovery point objective) of zero, meaning that no data is lost between the moment a failure occurs and the moment the system is restored to its last known good state. This is achieved through means like multiple nodes, multiple disks, and often multiple sites. Included is the combination of replication for small objects, such as retaining 2 or 3 copies of objects smaller than 60 kilobytes and erasure coding (EC) for larger objects. Erasure coding is a nuanced topic within the storage industry. Scality uses a sophisticated take on Erasure coding known as ARC (Advanced Resiliency Coding). In alignment with availability, is the durability of data that can be achieved through RING. This is to say, how “intact” can I believe my data at rest is? The Scality solution is a fourteen 9’s solution, exceeding most other advertised values, including that of AWS. What 9’s correspond to in terms of downtime in a single year can be found here, although it is telling that Wikipedia, as of early 2026, does not even provide calculations beyond twelve 9’s. Finally, in keeping with sound information lifecycle management (ILM), the Scality site may offer an additional server running XDM (eXtended Data Management) to act as a bridge between on-premises RING and public clouds such as AWS and Azure. This allows a tiering approach, where older, “cold” data is moved off-site. Archiving to-tape solutions are also available options. Scality – Quick Overview of Data at Rest Protection The two principal approaches to protecting data in large single or multi-site RING deployments is to combine replication and erasure coding. Replication is simple to understand, for smaller objects an operator simply chooses the number of replicas desired. If two replicas are chosen, indicated by class of service (COS) 2, two copies are spread across nodes. For COS 3, three copies are spread across nodes. A frequent rule of thumb is a three percent rule, this being the fraction of files frequently being 60 kilobytes or less across a full object storage environment, meaning they are to be replicated; replicas are available in cases of hardware disruptions with a given node. Erasure coding is an adjustable technique where larger objects are divided into data chunks, sometimes called data shards or data blocks, and spread (or “striped”) across many nodes. To add resilience, in the case of one or even more hardware issues with nodes or disks within nodes, additional parity chunks are mathematically derived. This way, cleverly and by design, only a subset of the data chunks and parity chunks are required in a solution under duress, and the original object is still easily provided upon an S3 request. In smaller node deployments, it is possible to consider a single RING server as two entities, but dividing storage into two “disk groups.” However, for an ideal, larger RING site, the approach depicted is preferred. The erasure coding depicted, normally referred to with the nomenclature EC(9,3), leads into a deeper design consideration where storage overhead is traded off against data resiliency. In the diagram, as many as 3 nodes holding portions of the data could become unreachable and still the erasure-coded object would be available. The overhead can be considered 33 percent as 3 additional parity chunks were created, beyond the 9 data chunks, and stored. For more risk-adverse operators, an EC of, say, EC(8,4) would allow even more, four points of failure. The trade off would be, in this case, a 50 percent overhead to achieve that increased resiliency. The overhead is still much less than replication, which can see hundreds of percent in overhead, thus the logical choice to use that for only small objects. Together, replication and EC lead to an overall storage efficiency number. Considering a 3 percent small objects environment, an EC(9,3) and COS3 for replication might tactically lead to a long-term palatable data protection posture, all for only a total cost of 41 percent additional storage overhead. The ability to scale out and protect the S3 data in flight is the domain of BIG-IP and what we will review next. BIG-IP – Bring Scale and Traffic Control to Scality RING A starting point for any discussion around BIG-IP are the rich load balancing algorithms and the ability to drop unhealthy nodes from an origin pool, transparent to users who only interact with the configured virtual server. Load balancing for S3 involves avoiding “hot spots”, where a single RING node might otherwise by overly tasked by users directly communicating to it, all while other nodes remain vastly underutilized. By steering DNS resolution of S3 services to BIG-IP, and configured virtual servers, traffic can be spread across all healthy nodes and spread in accordance with interesting algorithms. Popular ones for S3 include: Least Connections – RING nodes with fewer established TCP connections will receive proportionally more of the new S3 transactions, towards a goal of balanced load in the server cluster. Ratio (member) – Although sound practice would be all RING members having similar compute and storage makeup, in some cases, perhaps two vintages of server exist. Ratio will allow proportionally more traffic to target newer, more performant classes of Scality nodes. Fastest (Application) – The number of “in progress” transactions any one server in a pool is handling is considered. If traffic steered to all members is generally similar over time, a member with the least number of transactions actively in progress will be considered a faster member in the pool, and new transactions can favor such low latency servers. The RING nodes are contacted through Scality "S3 Connectors", in an all object deployment the connector resides on the storage node itself. For some configurations, perhaps one with file-based protocols like NFS concurrently running, the S3 Connectors can also be installed on VM or 1U appliances too. Of course, an unhealthy node should be precluded from an origin pool and the ability to do low-impact HTTP-based health monitors, like the HTTP HEAD method to see if an endpoint is responsive are frequently used. With BIG-IP Extended Application Validation (EAV) one can move towards even more sophisticated health checks. An S3 access and secret token pair installed on BIG-IP can be harnessed to perpetually upload and download small objects to each pool member, assuring the BIG-IP administrator that S3 is unequivocally healthy with each pool member. BIG-IP – Control-Plane and Data-Plane Safeguards A popular topic in a Scality software-defined distributed storage solution is that of a noisy neighbor when multiple tenants are considered. Perhaps one tenant has an S3 application which consumes disproportionate amounts of shared resources (CPU, network, or disk I/O), degrading performance for other tenants; controls are needed to counter this. With BIG-IP, a simple control plane threshold can be invoked with a straight-forward iRule, a programmatic rule which can limit the source from producing more than, say, 25 S3 requests over 10 seconds. An iRule is a powerful but normally short, event-driven script. A sample is provided below. Most modern generative AI solutions are well-versed in F5 iRules and can summarize even the most advanced scripts into digestible terms. This iRule examines an application (“client_addr”) that connects to a BIG-IP virtual server and starts a counter, after 10 transactions within 6 seconds the S3 commands will be rejected. The approach is that of a leaky bucket, and the application will be replenished with credits for future transactions over time. Whereas iRules frequently target layer 7, HTTP-layer activity, a wealth of layer 3 and layer 4 controls to limit data plane excessive consumption exist. Take for example the static bandwidth controller concept. Simply create a profile such as the following 10 Mbps example. This bandwidth controller can then be applied against a virtual server, including a virtual server supporting, say, lower-priority S3 application traffic. Focusing on layer-4, the TCP layer, a number of BIG-IP safeguards exist, amongst which are those that can defend against orphaned S3 connections, including those intentionally set up and left open by a bad actor to try to deplete RING resources. Another safeguard, the ability to re-map DiffServ code points or Type of Service (TOS) precedence bits exists. In this manner, a source that exceeds ideal traffic rates can be passed without intervention; however, by remapping heavy upstream traffic, BIG-IP enables network infrastructure adjacent to Scality RING nodes to police or discard such traffic if required. Evolving Modern S3 Traffic with Fresh Takes on TLS TLS underwent a major improvement with the first release of TLS 1.3 in 2018. It removed a number of antiquated security components from official support, things like RSA-style key agreements, SHA-1 hashes, and DES encryption. However, from a performance point of view, the upgrade to TLS 1.3 is equally significant. When establishing a TLS 1.2 session, perhaps towards the goal of an S3 transaction with RING, with a TCP connection established, an application can expect 2 round-trip times to successfully pass the TLS negotiation phase and move forward with encrypted communications. TLS1.3 cuts round trips in half; a new TLS 1.3 session can proceed to encrypted data exchange with a single round-trip time. In fact, when resuming a previously established TLS 1.3 session, 0RTT is possible, meaning the first resumption from the client can itself carry encrypted data. The following packet trace demonstrates 1RTT TLS1.3 establishment (double-click to enlarge image). To turn on this feature, simply use a client-facing TLS profile on BIG-IP and remove the “No TLS1.3” option. Another advancement in TLS, which must have TLS 1.3 enabled to start with, is quantum computing resistance to shared key agreement algorithms in TLS. This is a foundational building block of Post Quantum Computing (PCQ) cryptography, and the most well-known of these techniques is NIST FIPS-203 ML-KEM. The concern with not supporting PCQ today is that traffic in flight, which may be surreptitiously siphoned off and stored long term, will be readable in the future with quantum computers, perhaps as early as 2030. This risk stems from thought leadership like Shor’s algorithm, which indicates public key (asymmetric) cryptography, foundational to shared key establishment between parties in TLS, is at risk. The concern is that due to large-scale, fault-tolerant quantum computers potentially cracking elliptic curve cryptography (ECC) and Diffie-Helman (DH) algorithms. This risk, the so-called Harvest Now, Decrypt Later threat, means sensitive data like tax records, medical information and anything with longer term retention value requires protections today. It cannot be put off safely; action needs to be taken now. FIPS-203 ML-KEM suggests a hybrid approach to shared key derivation, after which TLS parties today can safely continue to use symmetric encryption algorithms like AES, which are thought to be far less susceptible to quantum attacks. Updating our initial one-site topology, we can consider the following improvements. A key understanding is that a hybrid key agreement scheme is used in FIPS -203. Essentially, a parallel set of crypto operations using traditional key agreements like X25519 ECDH key exchange protocol is performed simultaneously to the new MLKEM768 quantum resistant key encapsulation approach. The net result is a significant amount of crypto is carried out, with two sets of calculations, and the final combining of outcomes to come to an agreed upon shared key. The conclusion is this load is likely best suited for only a subset of S3 flows, those with objects housing PII of high long-term potential value. A method to achieve this balance, the trade off between security and performance, is to use multiple BIG-IP virtual servers: a regular set of S3 endpoints with classical TLS support, and higher-security S3 endpoints for selective use. The latter would support the PQC provisions of modern TLS. A full article on configuring BIG-IP for PQC, including a video demonstration of the click-through to add support to a virtual server, can be found here. Multi-site Global Server Load Balancing with BIG-IP and Scality RING An illustrative diagram showing two RING sites, asynchronously connected and offering S3 ingestion and object retrieval is shown below. Note that the BIG-IP DNS, although frequently deployed independently from BIG-IP LTM appliances, can operate on the same, existing LTM appliances as well. In this example, an S3 application physically situated in Phoenix, Arizona, in the American southwest, will use its configured local DNS resolver (frequently shorted to LDNS) to resolve S3 targets to IP addresses. Think, finance.s3.acme.com or humanresources.s3.acme.com. In F5 terms, these example domain names are referred to as “Wide IPs”. An organization such as the fictious acme.com will delegate the relevant sub-domains to F5 DNS, such as s3.acme.com in our example, meaning the F5 appliances in San Francisco and Boston hold the DNS nameservice (NS) resource records for the S3 domain in question, and can answer the client’s DNS resolver authoritatively. The DNS A queries required by the S3 application will land on either BIG-IP DNS platform, San Francisco or Boston. The pair serve for redundancy purposes, and both can provide an enterprise-controlled answer. In other words, should the S3 application target be resolved in Los Angeles or New York City? The F5 solution allows for a multitude of considerations when providing the answer to the above question. Interesting options and their impact on our topology diagram: Global Availability – A common disaster recovery approach. The BIG-IP DNS appliance distributes DNS name resolution requests to the first available virtual server in a pool list the administrator configures. BIG-IP DNS starts at the top of the list of virtual servers and sends requests to the first available virtual server in the list. Only when the virtual server becomes unavailable does BIG-IP DNS send requests to the next virtual server in the list. If we want S3 generally to travel to Los Angeles, and only utilize New York when application availability problems arise, this would be a good approach. Ratio – In a case where we would like a, say, 80/20 split between S3 traffic landing in Los Angeles versus New York, this would be a sound method. Perhaps market reasons make the cost of ingesting traffic in New York more expensive. Round Robin – the logical choice where we would like to see both data centers receive, generally, over time, the same amount of S3 transactions. Topology - BIG-IP DNS distributes DNS name resolution requests using proximity-based load balancing. BIG-IP DNS determines the proximity of the resource by comparing location information derived from the DNS message to the topology records in a topology statement. A great choice if data centers are of similar capacity and S3 transactions are best serviced by the closest physical data center. Note, the source IP address of the application’s DNS resolver is analyzed; if a centralized DNS service is used, perhaps it is not in Phoenix at all. There are techniques like EDNS0 to try to place the actual locality of the application. Round Trip Time – An advanced algorithm that is dynamic, not static. BIG-IP DNS distributes DNS name resolution requests to the virtual server with the fastest measured round-trip time between that data center and a client’s LDNS. This is achieved by having sites send low-impact probes, from “prober pools”, to each application’s DNS resolver over time. Therefore, for new DNS resolution requests, the BIG-IP DNS can tap into real-world latency knowledge to direct S3 traffic to the site, which is demonstrably known to offer the lowest latency. This again works best when the application and DNS resolver are in the same location. The BIG-IP DNS, when selecting between virtual servers, such as in Los Angeles and New York City in our simple example, can have a primary algorithm, a secondary algorithm and a fall-back, hard-coded IP. For instance, consider the first two algorithms are, in order, dynamic approaches, such as prober pools measuring round-trip time and, as a second approach, the measurement of active hop counts between sites and application LDNS. Should both methods fail to provide results, an IP address of last resort, perhaps in our case, Los Angeles, will be provided through the configured fall-back IP. Key takeaway: what is being provided by F5 and Scality is “intelligent” DNS, traffic is directed to the sites not based upon basic network reachability to Los Angeles or New York. In reality, the solution looks behind the local load balancing tier and is aware of the health of each Scality RING member. Thus, traffic is steered in accordance to back-end application health monitoring, something a regular DNS solution would not offer. Multi-site Solutions for Global Deployments and Geo-Awareness One potentially interesting use case for F5 BIG-IP DNS and Scality RING sites would be to tier all data centers into pools, based upon wider geographies. Consider a use case such as the following, with Scality RING sites spread across both North America and Europe. The BIG-IP DNS solution can handle this higher layer of abstraction, the first layer involves choosing between a pool of sites, before delving down one more layer into the pool of virtual servers spread across the sites within the optimal region. Policy is driving the response to a DNS query for S3 services all the way through these two layers. To explore all load balancing methods is an interesting exercise but beyond the scope of this article. The manual here drills into the possible options. To direct traffic at the country or even continent level, one can follow the “Topology” algorithm for first selecting the correct site pool. Persistence can be enabled, allowing future requests from the same LDNS resolver to follow prior outcomes. First, it is good practice to ensure the geo-IP database of BIG-IP is up to date. A brief video here steps a user through the update. The next thing to create is regions. In this diagram the user has created an “Americas” and “Europe” region. In fact, in this particular setup, the Europe region is seen to match all traffic with DNS queries originating outside of North and South American, per the list of member continents. With regions defined, now the one creates simple topology records to control DNS responses for S3 services based upon the source IP of DNS queries on behalf of S3 applications. The net result is a worldwide set of controls with regard to which Scality site S3 transactions will land upon. The decision based upon enterprise objectives can fully consider geographies like continents or individual countries. In our example, once a source region has been decided upon for an inbound DNS request, any of the previous algorithms can kick in. This would include options like global availability for DR within the selected regions, or perhaps measured latency to steer traffic to the most performant site in the region. Summary Scality RING is a software-defined object and file solution that supports data resiliency at levels expected by risk-adverse storage groups, all with contemporary Linux-friendly hardware platforms selected by the enterprise. The F5 BIG-IP application delivery controller complements S3 object traffic involving Scality, through massive scale out of nodes coupled with innovative algorithms for agile spreading of the traffic. Health of RING nodes is perpetually monitored so as to seamlessly bypass any troubled system. When moving to multi-site RING deployments, within a country or even across continents, BIG-IP DNS is harnessed to steer traffic to the optimal site, potentially including geo-ip rules, proximity between user and data center, and established baseline latencies offered by each site to the S3 application’s home location.61Views1like0CommentsA Guide to Cohesive and Purpose-Built Security
Have you ever been to a concert? Think of all the security involved just for somebody to sing you a few songs. You can’t just have one person at the entrance to check your ticket and that’s it. You need security personnel, bag checkers, security cameras, etc. You can’t use a bag checker to monitor security cameras. In the same way, you can’t use a WAF to prevent sophisticated bots. If a concert needs purpose-driven solutions for individual concerns, so does your company and its applications. Each attack vector requires a purpose-built solution- yet all these solutions need to work together in a cohesive manner. Customers commonly hear this and ask, is it really all vital? Do I need it all? Do these solutions work together? The answer is yes. It’s all vital in different ways, purpose-built problems require purpose-built solutions. L7 Web Application Firewall - WAF Many Web Application Firewalls (WAF) are focused on protecting against known L7 attacks that trigger various signatures to block malicious traffic, including things like the OWASP Top 10, Cross-Site Scripting, Malicious File Upload, etc. A WAF generally looks at malicious events occurring in the moment and blocks based on triggered signatures or detections. But to be more specific, a Layer 7 WAF scrutinizes all incoming web traffic, protecting your web application from malicious requests and ensuring that only legitimate traffic is allowed in. Bot Mitigation Now let’s look at bot mitigation as a strategy. A bot mitigation strategy needs to include a solution able to identify known bot networks while also providing strategies to accurately identify and prevent attackers with malicious intentions. Benign bots exist as well, but they include things like site crawlers or chatbots that people typically don’t care to protect against. Due to this, the bot mitigation strategy will not discuss these types of bots and instead focus on malicious bots. These types of attacks are incredibly difficult to detect since the attack is designed to interact with the application and emulate human behavior, utilizing automation to appear as though the application is being used as it is intended. Due to the nature of human-emulating and automated attacks, a purpose-built solution is necessary to analyze various pieces of telemetry to evaluate whether a user’s behavior is of human or automated origin. Examples of these malicious intentions include account takeovers, card cracking, or fraudulent purchases. These events can result in exposed PII, latency, and can cause your customers to lose faith in your company’s ability to handle their information. Having both a WAF and a bot mitigation strategy work well together because a WAF blocks attackers trying to break into your application, whereas a bot mitigation strategy focuses on the other side of that coin, attackers using your application as it’s intended but with malicious intentions. Behavioral Analysis Another solution that should be in every security stack is a behavioral analysis-based solution. What does it pair well with? WAF and a bot mitigation strategy. As previously mentioned, a WAF typically blocks based on signatures, whereas a bot mitigation strategy blocks people using your application as it’s intended, but with malicious intent. A solution that utilizes machine learning to perform behavioral analysis is doing something else entirely. It uses the aforementioned machine learning to look at a variety of vectors to generate a baseline of your traffic and identify outliers based on the keys that you specify. From there, it can block and recognize when something malicious appears outside of the baseline. Utilizing that baseline, the solution can also look at events over time and catch attackers that might stop for now but come back later. API Security Next up, securing your API (Application Programming Interface) endpoints. APIs make requests to your application for information. But what happens when that API endpoint is unsecured? What happens when it contains sensitive data? It results in things like stolen credentials, unauthorized access, and data leaks, among other things. (The OWASP API Top 10 references some areas of concern as well) APIs are accessing data in your application all day long; therefore, your APIs need to be known and secured. Some people like to think of API Protection and WAF as the same thing and only requiring one solution. Personally, I do not. A WAF is typically looking at signatures, and yes, some API traffic might match those signatures, but not always. What if you’re expecting a POST, but you instead see a GET? Is a WAF signature going to catch that? Not likely. But a purpose-built API Protection solution with schema enforcement can certainly aid in solving that problem. API Security and WAF go hand in hand because they solve for vulnerabilities in different yet similar attack vectors, but they’re not the same. Let’s recap. Do you need all the different security solutions? Can we create a cohesive picture of security? The answer is undoubtedly, yes. Let’s go back to our concert. Concert - Security Personnel Concert Security Personnel (Web Application Firewall): Throughout the venue, from the entrance to the concert floor, security personnel constantly watch the venue, keeping a lookout for disruptive behavior. If they spot something or someone that could disrupt the event, they step in to handle the situation. Think of a person walking in with a prohibited item like a weapon. We’d want to remove them because they had something matching the description of an item we do not allow at the concert. Similarly, a web application firewall (WAF) acts as security personnel for your web application, filtering out malicious traffic through the ability to look at a variety of signatures and ensuring nobody at the concert is matching those signatures and violations a WAF uses to mitigate threats. Concert - Entrance Security Entrance Security Personnel (Bot Mitigation Strategy): Concert security personnel are stationed at the entrance of the arena, checking everyone who comes in. They ensure that only the actual ticketed attendees are allowed inside. Bot mitigation works similarly by identifying application traffic with highly efficient signal sets, accurately thwarting automated threats, impersonations, account takeovers, and other automation-based threat vectors. Accurately blocking malicious automated traffic ensures only real users/humans get through. We only want to let ticketed people through the door. Concert - Initial Screening Initial Screening (Malicious User Mitigation): In many concerts today, pre-screening occurs where security scanners, bag checks, ID checks (depending on the venue) are performed. Those who are exhibiting non-compliance are turned away. This could even be screening for people who have had non-compliant behavior at prior concerts, letting the team know to keep an eye on them in case they might go back to their trouble causing ways. This way, if they cause problems for us later, we catch them quickly because we already know they could be troublemakers. Similarly, malicious user mitigation acts first. It involves monitoring your traffic and creating a baseline to identify and mitigate any users who exhibit malicious or suspicious behavior. This identification, driven by machine learning across various security signals, enforces a first-line defense strategy to block malicious activity. Concert - Access Control Access Control for Special Areas (API Security): There are other concert entrances where the band may enter or all the involved work to put on a concert flows through. These are further controlled and restricted areas within the venue such as backstage or the sound booths, that require special access passes. These passes are carefully controlled to ensure that only authorized personnel can enter these areas. API protection does the same thing for your web application’s interfaces, ensuring that only authorized systems and users can interact with your APIs, therefore protecting sensitive data and functionalities from unauthorized access. Just like you need all the security personnel at a concert to feel secure, you need it all to keep your applications secure. Summary Each solution in your security stack should have a specific purpose and protect all the portions of your application, hence requiring a purpose-built solution for each. Without these protections, you’re leaving yourself vulnerable. In creating such a stack, a robust defense is created that covers a variety of attack vectors, such as preventing malicious access, managing automated threats, mitigating harmful behavior, and protecting sensitive data. F5 Distributed Cloud brings all the tools into focus in a single interface, giving you the ability to secure your applications, including the most critical ones, efficiently and effectively. Here are a few quick points about what F5 offers to help provide the aforementioned: comprehensive security stack. F5 Distributed Cloud WAAP (Web App and API Protection) F5 addresses the WAF and API Protection under one title, but they are different solutions. Our F5 Distributed Cloud WAF has over 8,000 robust signatures that have been built up over the last 20 years. It is also incredibly easy to implement and opt-out-based to make that easy implementation even easier. Regarding the F5 Distributed Cloud API Protection portion, our API protection sits in line to perform both discovery and protection, in a single dashboard that provides per-endpoint rate limiting and protections alongside incredible visibility. F5 Distributed Cloud Bot Defense F5 addresses having a bot mitigation strategy through 4 different tiers of bot defense, one of which is included in the WAF that has over 8,000 robust signatures. The other tiers use a variety of signals, including environmental signals, behavioral signals, and network signals. The F5 Distributed Cloud Bot Defense aids in protecting your environment from automated threats that bots may cause. Protecting your application, and your customers’ information. F5 Malicious User Detection and Mitigation On the F5 platform, we can provide a machine-learning-based solution that generates a baseline of your traffic and based on a user identifier you specify, you’re able to see what a user comes outside of that baseline and maybe isn’t who they say they are. F5 Distributed Cloud brings all these tools into focus in a single SaaS-driven Console, giving you the ability to secure your applications, including the most critical ones (yes even AI apps!), efficiently and effectively.40Views1like0CommentsF5 Container Ingress Services (CIS) deployment using Cilium CNI and static routes
F5 Container Ingress Services (CIS) supports static route configuration to enable direct routing from F5 BIG-IP to Kubernetes/OpenShift Pods as an alternative to VXLAN tunnels. Static routes are enabled in the F5 CIS CLI/Helm yaml manifest using the argument --static-routing-mode=true. In this article, we will use Cilium as the Container Network Interface (CNI) and configure static routes for an NGINX deployment For initial configuration of the BIG-IP, including AS3 installation, please see https://clouddocs.f5.com/products/extensions/f5-appsvcs-extension/latest/userguide/installation.html and https://clouddocs.f5.com/containers/latest/userguide/kubernetes/#cis-installation The first step is to install Cilium CNI using the steps below on Linux host: CILIUM_CLI_VERSION=$(curl -s https://raw.githubusercontent.com/cilium/cilium-cli/main/stable.txt) CLI_ARCH=amd64 if [ "$(uname -m)" = "aarch64" ]; then CLI_ARCH=arm64; fi curl -L --fail --remote-name-all https://github.com/cilium/cilium-cli/releases/download/${CILIUM_CLI_VERSION}/cilium-linux-${CLI_ARCH}.tar.gz{,.sha256sum} sha256sum --check cilium-linux-${CLI_ARCH}.tar.gz.sha256sum sudo tar xzvfC cilium-linux-${CLI_ARCH}.tar.gz /usr/local/bin rm cilium-linux-${CLI_ARCH}.tar.gz{,.sha256sum} cilium install --version 1.18.5 cilium status cilium status --wait root@ciliumk8s-ubuntu-server:~# cilium status --wait /¯¯\ /¯¯\__/¯¯\ Cilium: OK \__/¯¯\__/ Operator: OK /¯¯\__/¯¯\ Envoy DaemonSet: OK \__/¯¯\__/ Hubble Relay: disabled \__/ ClusterMesh: disabled DaemonSet cilium Desired: 1, Ready: 1/1, Available: 1/1 DaemonSet cilium-envoy Desired: 1, Ready: 1/1, Available: 1/1 Deployment cilium-operator Desired: 1, Ready: 1/1, Available: 1/1 Containers: cilium Running: 1 cilium-envoy Running: 1 cilium-operator Running: 1 clustermesh-apiserver hubble-relay Cluster Pods: 6/6 managed by Cilium Helm chart version: 1.18.3 Image versions cilium quay.io/cilium/cilium:v1.18.3@sha256:5649db451c88d928ea585514746d50d91e6210801b300c897283ea319d68de15: 1 cilium-envoy quay.io/cilium/cilium-envoy:v1.34.10-1761014632-c360e8557eb41011dfb5210f8fb53fed6c0b3222@sha256:ca76eb4e9812d114c7f43215a742c00b8bf41200992af0d21b5561d46156fd15: 1 cilium-operator quay.io/cilium/operator-generic:v1.18.3@sha256:b5a0138e1a38e4437c5215257ff4e35373619501f4877dbaf92c89ecfad81797: 1 cilium connectivity test root@ciliumk8s-ubuntu-server:~# cilium connectivity test ℹ️ Monitor aggregation detected, will skip some flow validation steps ✨ [default] Creating namespace cilium-test-1 for connectivity check... ✨ [default] Deploying echo-same-node service... ✨ [default] Deploying DNS test server configmap... ✨ [default] Deploying same-node deployment... ✨ [default] Deploying client deployment... ✨ [default] Deploying client2 deployment... ✨ [default] Deploying ccnp deployment... ⌛ [default] Waiting for deployment cilium-test-1/client to become ready... ⌛ [default] Waiting for deployment cilium-test-1/client2 to become ready... ⌛ [default] Waiting for deployment cilium-test-1/echo-same-node to become ready... ⌛ [default] Waiting for deployment cilium-test-ccnp1/client-ccnp to become ready... ⌛ [default] Waiting for deployment cilium-test-ccnp2/client-ccnp to become ready... ⌛ [default] Waiting for pod cilium-test-1/client-645b68dcf7-s5mdb to reach DNS server on cilium-test-1/echo-same-node-f5b8d454c-qkgq9 pod... ⌛ [default] Waiting for pod cilium-test-1/client2-66475877c6-cw7f5 to reach DNS server on cilium-test-1/echo-same-node-f5b8d454c-qkgq9 pod... ⌛ [default] Waiting for pod cilium-test-1/client-645b68dcf7-s5mdb to reach default/kubernetes service... ⌛ [default] Waiting for pod cilium-test-1/client2-66475877c6-cw7f5 to reach default/kubernetes service... ⌛ [default] Waiting for Service cilium-test-1/echo-same-node to become ready... ⌛ [default] Waiting for Service cilium-test-1/echo-same-node to be synchronized by Cilium pod kube-system/cilium-lxjxf ⌛ [default] Waiting for NodePort 10.69.12.2:32046 (cilium-test-1/echo-same-node) to become ready... 🔭 Enabling Hubble telescope... ⚠️ Unable to contact Hubble Relay, disabling Hubble telescope and flow validation: rpc error: code = Unavailable desc = connection error: desc = "transport: Error while dialing: dial tcp 127.0.0.1:4245: connect: connection refused" ℹ️ Expose Relay locally with: cilium hubble enable cilium hubble port-forward& ℹ️ Cilium version: 1.18.3 🏃[cilium-test-1] Running 126 tests ... [=] [cilium-test-1] Test [no-policies] [1/126] .................... [=] [cilium-test-1] Skipping test [no-policies-from-outside] [2/126] (skipped by condition) [=] [cilium-test-1] Test [no-policies-extra] [3/126] <- snip -> For this article, we will install k3s with Cilium CNI root@ciliumk8s-ubuntu-server:~# curl -sfL https://get.k3s.io | sh -s - --flannel-backend=none --disable-kube-proxy --disable servicelb --disable-network-policy --disable traefik --cluster-init --node-ip=10.69.12.2 --cluster-cidr=10.42.0.0/16 root@ciliumk8s-ubuntu-server:~# mkdir -p $HOME/.kube root@ciliumk8s-ubuntu-server:~# sudo cp -i /etc/rancher/k3s/k3s.yaml $HOME/.kube/config root@ciliumk8s-ubuntu-server:~# sudo chown $(id -u):$(id -g) $HOME/.kube/config root@ciliumk8s-ubuntu-server:~# echo "export KUBECONFIG=$HOME/.kube/config" >> $HOME/.bashrc root@ciliumk8s-ubuntu-server:~# source $HOME/.bashrc API_SERVER_IP=10.69.12.2 API_SERVER_PORT=6443 CLUSTER_ID=1 CLUSTER_NAME=`hostname` POD_CIDR="10.42.0.0/16" root@ciliumk8s-ubuntu-server:~# cilium install --set cluster.id=${CLUSTER_ID} --set cluster.name=${CLUSTER_NAME} --set k8sServiceHost=${API_SERVER_IP} --set k8sServicePort=${API_SERVER_PORT} --set ipam.operator.clusterPoolIPv4PodCIDRList=$POD_CIDR --set kubeProxyReplacement=true --helm-set=operator.replicas=1 root@ciliumk8s-ubuntu-server:~# cilium config view | grep cluster bpf-lb-external-clusterip false cluster-id 1 cluster-name ciliumk8s-ubuntu-server cluster-pool-ipv4-cidr 10.42.0.0/16 cluster-pool-ipv4-mask-size 24 clustermesh-enable-endpoint-sync false clustermesh-enable-mcs-api false ipam cluster-pool max-connected-clusters 255 policy-default-local-cluster false root@ciliumk8s-ubuntu-server:~# cilium status --wait The F5 CIS yaml manifest for deployment using Helm Note that these arguments are required for CIS to leverage static routes static-routing-mode: true orchestration-cni: cilium-k8s We will also be installing custom resources, so this argument is also required 3. custom-resource-mode: true Values yaml manifest for Helm deployment bigip_login_secret: f5-bigip-ctlr-login bigip_secret: create: false username: password: rbac: create: true serviceAccount: # Specifies whether a service account should be created create: true # The name of the service account to use. # If not set and create is true, a name is generated using the fullname template name: k8s-bigip-ctlr # This namespace is where the Controller lives; namespace: kube-system ingressClass: create: true ingressClassName: f5 isDefaultIngressController: true args: # See https://clouddocs.f5.com/containers/latest/userguide/config-parameters.html # NOTE: helm has difficulty with values using `-`; `_` are used for naming # and are replaced with `-` during rendering. # REQUIRED Params bigip_url: X.X.X.S bigip_partition: <BIG-IP_PARTITION> # OPTIONAL PARAMS -- uncomment and provide values for those you wish to use. static-routing-mode: true orchestration-cni: cilium-k8s # verify_interval: # node-poll_interval: # log_level: DEBUG # python_basedir: ~ # VXLAN # openshift_sdn_name: # flannel_name: cilium-vxlan # KUBERNETES # default_ingress_ip: # kubeconfig: # namespaces: ["foo", "bar"] # namespace_label: # node_label_selector: pool_member_type: cluster # resolve_ingress_names: # running_in_cluster: # use_node_internal: # use_secrets: insecure: true custom-resource-mode: true log-as3-response: true as3-validation: true # gtm-bigip-password # gtm-bigip-url # gtm-bigip-username # ipam : true image: # Use the tag to target a specific version of the Controller user: f5networks repo: k8s-bigip-ctlr pullPolicy: Always version: latest # affinity: # nodeAffinity: # requiredDuringSchedulingIgnoredDuringExecution: # nodeSelectorTerms: # - matchExpressions: # - key: kubernetes.io/arch # operator: Exists # securityContext: # runAsUser: 1000 # runAsGroup: 3000 # fsGroup: 2000 # If you want to specify resources, uncomment the following # limits_cpu: 100m # limits_memory: 512Mi # requests_cpu: 100m # requests_memory: 512Mi # Set podSecurityContext for Pod Security Admission and Pod Security Standards # podSecurityContext: # runAsUser: 1000 # runAsGroup: 1000 # privileged: true Installation steps for deploying F5 CIS using helm can be found in this link https://clouddocs.f5.com/containers/latest/userguide/kubernetes/ Once F5 CIS is validated to be up and running, we can now deploy the following application example root@ciliumk8s-ubuntu-server:~# cat application.yaml apiVersion: cis.f5.com/v1 kind: VirtualServer metadata: labels: f5cr: "true" name: goblin-virtual-server namespace: nsgoblin spec: host: goblin.com pools: - path: /green service: svc-nodeport servicePort: 80 - path: /harry service: svc-nodeport servicePort: 80 virtualServerAddress: X.X.X.X --- apiVersion: apps/v1 kind: Deployment metadata: name: goblin-backend namespace: nsgoblin spec: replicas: 2 selector: matchLabels: app: goblin-backend template: metadata: labels: app: goblin-backend spec: containers: - name: goblin-backend image: nginx:latest ports: - containerPort: 80 --- apiVersion: v1 kind: Service metadata: name: svc-nodeport namespace: nsgoblin spec: selector: app: goblin-backend ports: - port: 80 targetPort: 80 type: ClusterIP k apply -f application.yaml We can now verify the k8s pods are created. Then we will create a sample html page to test access to the backend NGINX pod root@ciliumk8s-ubuntu-server:~# k -n nsgoblin get po -owide NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES goblin-backend-7485b6dcdf-d5t48 1/1 Running 0 6d2h 10.42.0.70 ciliumk8s-ubuntu-server <none> <none> goblin-backend-7485b6dcdf-pt7hx 1/1 Running 0 6d2h 10.42.0.97 ciliumk8s-ubuntu-server <none> <none> root@ciliumk8s-ubuntu-server:~# k -n nsgoblin exec -it po/goblin-backend-7485b6dcdf-pt7hx -- /bin/sh # cat > green <<'EOF' <!DOCTYPE html> > > <html> > <head> <title>Green Goblin</title> <style> body { background-color: #4CAF50; color: white; text-align: center; padding: 50px; } h1 { font-size: 3em; } > > > > > </style> </head> <body> <h1>I am the green goblin!</h1> <p>Access me at /green</p> </body> </html> > > > > > > > EOF root@ciliumk8s-ubuntu-server:~# k -n nsgoblin exec -it goblin-backend-7485b6dcdf-d5t48 -- /bin/sh # cat > green <<'EOF' > <!DOCTYPE html> <html> <head> <title>Green Goblin</title> <style> body { background-color: #4CAF50; color: white; text-align: center; padding: 50px; } h1 { font-size: 3em; } </style> > </head> <body> <h1>I am the green goblin!</h1> <p>Access me at /green</p> </body> </html> EOF> > > > > > > > > > > > > We can now validate the pools are created on the F5 BIG-IP root@(ciliumk8s-bigip)(cfg-sync Standalone)(Active)(/kubernetes/Shared)(tmos)# list ltm pool all ltm pool svc_nodeport_80_nsgoblin_goblin_com_green { description "crd_10_69_12_40_80 loadbalances this pool" members { /kubernetes/10.42.0.70:http { address 10.42.0.70 } /kubernetes/10.42.0.97:http { address 10.42.0.97 } } min-active-members 1 partition kubernetes } ltm pool svc_nodeport_80_nsgoblin_goblin_com_harry { description "crd_10_69_12_40_80 loadbalances this pool" members { /kubernetes/10.42.0.70:http { address 10.42.0.70 } /kubernetes/10.42.0.97:http { address 10.42.0.97 } } min-active-members 1 partition kubernetes } root@(ciliumk8s-bigip)(cfg-sync Standalone)(Active)(/kubernetes/Shared)(tmos)# list ltm virtual crd_10_69_12_40_80 ltm virtual crd_10_69_12_40_80 { creation-time 2025-12-22:10:10:37 description Shared destination /kubernetes/10.69.12.40:http ip-protocol tcp last-modified-time 2025-12-22:10:10:37 mask 255.255.255.255 partition kubernetes persist { /Common/cookie { default yes } } policies { crd_10_69_12_40_80_goblin_com_policy { } } profiles { /Common/f5-tcp-progressive { } /Common/http { } } serverssl-use-sni disabled source 0.0.0.0/0 source-address-translation { type automap } translate-address enabled translate-port enabled vs-index 2 } CIS log output 2025/12/22 18:10:25 [INFO] [Request: 1] cluster local requested CREATE in VIRTUALSERVER nsgoblin/goblin-virtual-server 2025/12/22 18:10:25 [INFO] [Request: 1][AS3] creating a new AS3 manifest 2025/12/22 18:10:25 [INFO] [Request: 1][AS3][BigIP] posting request to https://10.69.12.1 for tenants 2025/12/22 18:10:26 [INFO] [Request: 2] cluster local requested UPDATE in ENDPOINTS nsgoblin/svc-nodeport 2025/12/22 18:10:26 [INFO] [Request: 3] cluster local requested UPDATE in ENDPOINTS nsgoblin/svc-nodeport 2025/12/22 18:10:43 [INFO] [Request: 1][AS3][BigIP] post resulted in SUCCESS 2025/12/22 18:10:43 [INFO] [AS3][POST] SUCCESS: code: 200 --- tenant:kubernetes --- message: success 2025/12/22 18:10:43 [INFO] [Request: 3][AS3] Processing request 2025/12/22 18:10:43 [INFO] [Request: 3][AS3] creating a new AS3 manifest 2025/12/22 18:10:43 [INFO] [Request: 3][AS3][BigIP] posting request to https://10.69.12.1 for tenants 2025/12/22 18:10:43 [INFO] Successfully updated status of VirtualServer:nsgoblin/goblin-virtual-server in Cluster W1222 18:10:49.238444 1 warnings.go:70] v1 Endpoints is deprecated in v1.33+; use discovery.k8s.io/v1 EndpointSlice 2025/12/22 18:10:52 [INFO] [Request: 3][AS3][BigIP] post resulted in SUCCESS 2025/12/22 18:10:52 [INFO] [AS3][POST] SUCCESS: code: 200 --- tenant:kubernetes --- message: success 2025/12/22 18:10:52 [INFO] Successfully updated status of VirtualServer:nsgoblin/goblin-virtual-server in Cluster Troubleshooting: 1. If static routes are not added, the first step is to inspect CIS logs for entries similar to these: Cilium annotation warning logs 2025/12/22 17:44:45 [WARNING] Cilium node podCIDR annotation not found on node ciliumk8s-ubuntu-server, node has spec.podCIDR ? 2025/12/22 17:46:41 [WARNING] Cilium node podCIDR annotation not found on node ciliumk8s-ubuntu-server, node has spec.podCIDR ? 2025/12/22 17:46:42 [WARNING] Cilium node podCIDR annotation not found on node ciliumk8s-ubuntu-server, node has spec.podCIDR ? 2025/12/22 17:46:43 [WARNING] Cilium node podCIDR annotation not found on node ciliumk8s-ubuntu-server, node has spec.podCIDR ? 2. These are resolved by adding annotations to the node using the reference: https://clouddocs.f5.com/containers/latest/userguide/static-route-support.html Cilium annotation for node root@ciliumk8s-ubuntu-server:~# k annotate node ciliumk8s-ubuntu-server io.cilium.network.ipv4-pod-cidr=10.42.0.0/16 root@ciliumk8s-ubuntu-server:~# k describe node | grep -E "Annotations:|PodCIDR:|^\s+.*pod-cidr" Annotations: alpha.kubernetes.io/provided-node-ip: 10.69.12.2 io.cilium.network.ipv4-pod-cidr: 10.42.0.0/16 PodCIDR: 10.42.0.0/24 3. Verify a static route has been created and test connectivity to k8s pods root@(ciliumk8s-bigip)(cfg-sync Standalone)(Active)(/kubernetes)(tmos)# list net route net route k8s-ciliumk8s-ubuntu-server-10.69.12.2 { description 10.69.12.1 gw 10.69.12.2 network 10.42.0.0/16 partition kubernetes } Using pup (command line HTML parser) -> https://commandmasters.com/commands/pup-common/ root@ciliumk8s-ubuntu-server:~# curl -s http://goblin.com/green | pup 'body text{}' I am the green goblin! Access me at /green 1 0.000000 10.69.12.34 ? 10.69.12.40 TCP 78 34294 ? 80 [SYN] Seq=0 Win=64240 Len=0 MSS=1460 SACK_PERM TSval=2984295232 TSecr=0 WS=128 2 0.000045 10.69.12.40 ? 10.69.12.34 TCP 78 80 ? 34294 [SYN, ACK] Seq=0 Ack=1 Win=23360 Len=0 MSS=1460 WS=512 SACK_PERM TSval=1809316303 TSecr=2984295232 3 0.001134 10.69.12.34 ? 10.69.12.40 TCP 70 34294 ? 80 [ACK] Seq=1 Ack=1 Win=64256 Len=0 TSval=2984295234 TSecr=1809316303 4 0.001151 10.69.12.34 ? 10.69.12.40 HTTP 149 GET /green HTTP/1.1 5 0.001343 10.69.12.40 ? 10.69.12.34 TCP 70 80 ? 34294 [ACK] Seq=1 Ack=80 Win=23040 Len=0 TSval=1809316304 TSecr=2984295234 6 0.002497 10.69.12.1 ? 10.42.0.97 TCP 78 33707 ? 80 [SYN] Seq=0 Win=23360 Len=0 MSS=1460 WS=512 SACK_PERM TSval=1809316304 TSecr=0 7 0.003614 10.42.0.97 ? 10.69.12.1 TCP 78 80 ? 33707 [SYN, ACK] Seq=0 Ack=1 Win=64308 Len=0 MSS=1410 SACK_PERM TSval=1012609408 TSecr=1809316304 WS=128 8 0.003636 10.69.12.1 ? 10.42.0.97 TCP 70 33707 ? 80 [ACK] Seq=1 Ack=1 Win=23040 Len=0 TSval=1809316307 TSecr=1012609408 9 0.003680 10.69.12.1 ? 10.42.0.97 HTTP 149 GET /green HTTP/1.1 10 0.004774 10.42.0.97 ? 10.69.12.1 TCP 70 80 ? 33707 [ACK] Seq=1 Ack=80 Win=64256 Len=0 TSval=1012609409 TSecr=1809316307 11 0.004790 10.42.0.97 ? 10.69.12.1 TCP 323 HTTP/1.1 200 OK [TCP segment of a reassembled PDU] 12 0.004796 10.42.0.97 ? 10.69.12.1 HTTP 384 HTTP/1.1 200 OK 13 0.004820 10.69.12.40 ? 10.69.12.34 TCP 448 HTTP/1.1 200 OK [TCP segment of a reassembled PDU] 14 0.004838 10.69.12.1 ? 10.42.0.97 TCP 70 33707 ? 80 [ACK] Seq=80 Ack=254 Win=23552 Len=0 TSval=1809316308 TSecr=1012609410 15 0.004854 10.69.12.40 ? 10.69.12.34 HTTP 384 HTTP/1.1 200 OK Summary: There we have it, we have successfully deployed an NGINX application on a Kubernetes cluster managed by F5 CIS using static routes to forward traffic to the kubernetes pods39Views2likes0CommentsBIG-IP Next for Kubernetes CNF 2.2 what's new
Introduction BIG-IP Next CNF v2.2.0 offers new enhancements to BIG-IP Next for Kubernetes CNFs with a focus on analytics capabilities, traffic distribution, subscriber management, and operational improvements that address real-world challenges in high-scale deployments. High-Speed Logging for Traffic Analysis The Reporting feature introduces high-speed logging (HSL) capabilities that capture session and flow-level metrics in CSV format. Key data points include subscriber identifiers, traffic volumes, transaction counts, video resolution metrics, and latency measurements, exported via Syslog (RFC5424, RFC3164, or legacy-BIG-IP formats) over TCP or UDP. Fluent-bit handles TMM container log processing, forwarding to Fluentd for external analytics servers. Custom Resources simplify configuration of log publishers, reporting intervals, and enforcement policies, making it straightforward to integrate into existing Kubernetes workflows. DNS Cache Inspection and Management New utilities provide detailed visibility into DNS cache operations. The bdt_cli tool supports listing, counting, and selectively deleting cache records using filters for domain names, TTL ranges, response codes, and cache types (RRSet, message, or nameserver). Complementing this, dns-cache-stats delivers performance metrics including hit/miss ratios, query volumes, response time distributions across intervals, and nameserver behavior patterns. These tools enable systematic cache analysis and maintenance directly from debug sidecars. Stateless and Bidirectional DAG Traffic Distribution Stateless DAG implements pod-based hashing to distribute traffic evenly across TMM pods without maintaining flow state. This approach embeds directly within the CNE installation, eliminating separate DAG infrastructure. Bidirectional DAG extends this with symmetric routing for client-to-server and return flows, using consistent redirect VLANs and hash tables. Deployments must align TMM pod counts with self-IP configurations on pod_hash-enabled VLANs to ensure balanced distribution. Dynamic GeoDB Updates for Edge Firewall Policies Edge Firewall Geo Location policies now support dynamic GeoDB updates, replacing static country/region lists embedded in container images. The Controller and PCCD components automatically incorporate new locations and handle deprecated entries with appropriate logging. Firewall Policy CRs can reference newly available geos immediately, enabling responsive policy adjustments without container restarts or rebuilds. This maintains policy currency in environments requiring frequent threat intelligence updates. Subscriber Creation and CGNAT Logging RADIUS-triggered subscriber creation integrates with distributed session storage (DSSM) for real-time synchronization across TMM pods. Subscriber records capture identifiers like IMSI, MSISDN, or NAI, enabling automated session lifecycle management. CGNAT logging enhancements include Subscriber ID in translation events, providing clear IP-to-subscriber mapping. This facilitates correlation of network activity with individual users, supporting troubleshooting, auditing, and regulatory reporting requirements. Kubernetes Secrets Integration for Sensitive Configuration Custom Resources now reference sensitive data through Kubernetes’ native Secrets using secretRef fields (name, namespace, key). The cne-controller fetches secrets securely via mTLS, monitors for updates, and propagates changes to consuming components. This supports certificate rotation through cert-manager without CR reapplication. RBAC controls ensure appropriate access while eliminating plaintext sensitive data from YAML manifests. Dynamic Log Management and Storage Optimization REST API endpoints and ConfigMap watching enable runtime log level adjustments per pod without restarts. Changes propagate through pod-specific ConfigMaps monitored by the F5 logging library. An optional Folder Cleaner CronJob automatically removes orphaned log directories, preventing storage exhaustion in long-running deployments with heavy Fluentd usage. Key Enhancements Overview Several refinements have improved operational aspects: CNE Controller RBAC: Configurable CRD monitoring via ConfigMap eliminates cluster-wide list permissions, with manual controller restart required for list changes. CGNAT/DNAT HA: F5Ingress automatically distributes VLAN configurations to standby TMM pods (excluding self-IPs) for seamless failover. Memory Optimization: 1GB huge page support via tmm.hugepages.preferredhugepagesize parameter. Diagnostics: QKView requests can be canceled by ID, generating partial diagnostics from collected data. Metrics Control: Per-table aggregation modes (Aggregated, Semi-Aggregated, Diagnostic) with configurable export intervals via f5-observer-operator-config ConfigMap. Related content BIG-IP Next for Kubernetes CNF - latest release BIG-IP Next Cloud-Native Network Functions (CNFs) BIG-IP Next for Kubernetes CNFs deployment walkthrough | DevCentral BIG-IP Next Edge Firewall CNF for Edge workloads | DevCentral F5 BIG-IP Next CNF solutions suite of Kubernetes native 5G Network Functions66Views2likes0CommentsAI Inference for VLLM models with F5 BIG-IP & Red Hat OpenShift
This article shows how to perform Intelligent Load Balancing for AI workloads using the new features of BIG-IP v21 and Red Hat OpenShift. Intelligent Load Balancing is done based on business logic rules without iRule programming and state metrics of the VLLM inference servers gathered from OpenShift´s Prometheus.253Views1like4CommentsMulti‑Cluster Kubernetes App Delivery Made Simple with F5 BIG‑IP CIS & Nutanix Kubernetes Platform
Organizations are increasingly deploying applications across multiple Kubernetes clusters to achieve greater resilience, scalability, and operational flexibility. However, as environments expand, so does the complexity. Managing traffic, ensuring consistent security policies, and delivering applications seamlessly across multiple Kubernetes clusters can quickly become operationally overwhelming. F5 and Nutanix jointly address these challenges together by combining the application delivery and security capabilities of F5 BIG-IP with the simplicity and operational consistency of the Nutanix Kubernetes Platform (NKP). See it in action—watch the demo video: F5 BIG-IP Container Ingress Services (CIS) Overview F5 BIG‑IP Container Ingress Services (CIS) is a Kubernetes‑native ingress and automation controller that connects F5 BIG‑IP directly to Kubernetes. F5 BIG-IP CIS watches the Kubernetes API in real time and translates native Kubernetes resources—including Ingress, Routes, VirtualServer, TransportServer, and AS3 declarations—into F5 BIG‑IP configurations. This transforms F5 BIG‑IP from an external appliance into a declarative, automated extension of the Kubernetes environment, enabling cloud‑native workflows and eliminating manual, error‑prone configuration. This tight integration ensures that application delivery, security, and traffic management remain consistent and automatically adapt as Kubernetes environments change. Multi-Cluster Application Delivery with CIS Multi-cluster architectures are rapidly becoming the enterprise standard. But delivering applications across multiple Kubernetes clusters introduces challenges, including: Maintaining consistent security policies Automatically routing traffic to the most appropriate cluster as workloads scale or shift Avoiding configuration drift and fragmented visibility Reducing operational friction caused by manual updates Without the right tooling, these challenges can lead to operational sprawl and deployment delays. F5 BIG-IP CIS addresses these challenges through its built‑in multi‑cluster capabilities, enabling a single BIG‑IP Virtual Server to front applications that span multiple Kubernetes clusters. This approach: Consolidates application access behind one unified entry point Automatically updates traffic routing as clusters scale or workloads migrate Enforces consistent policies across environments Significantly reduces operational overhead by eliminating per‑cluster configuration F5 BIG-IP CIS supports both standalone mode and high‑availability (HA) mode for multi-cluster environments. In HA mode, the primary F5 BIG-IP CIS instance is responsible for managing F5 BIG‑IP configuration, while a secondary instance continuously monitors its health. If the primary instance becomes unavailable, the secondary automatically takes over, ensuring uninterrupted management and application delivery continuity. F5 BIG-IP CIS + Nutanix Kubernetes Platform (NKP): Better Together When F5 BIG‑IP CIS is combined with the Nutanix Kubernetes Platform (NKP), organizations gain a unified and automated approach to delivering, securing, and scaling applications across multiple Kubernetes clusters—a cohesive multi‑cluster application services solution. Key benefits include: Unified North–South Control Plane F5 BIG‑IP acts as the intelligent front door for all Kubernetes clusters, centralizing traffic management and visibility. Consistent Security Policies WAF, DDoS protection, and traffic policies can be applied uniformly across Kubernetes clusters to maintain a consistent security posture. Automated Orchestration and Reduced Operational Overhead F5 BIG-IP CIS’s event‑driven automation aligns with NKP’s streamlined cluster lifecycle management, reducing manual configuration and operational complexity. Direct Pod Routing in Cluster Mode Static route support in cluster mode enables CIS to automatically configure static routes on BIG‑IP using the node subnets assigned to Kubernetes cluster nodes. This allows BIG‑IP to route directly to Kubernetes pod subnets without requiring any tunnel configuration, greatly simplifying the networking architecture. Flexible Deployment Topologies: Standalone or HA CIS supports both standalone and high‑availability deployment in multi-cluster environments, enabling resilient application exposure across Kubernetes clusters. Conclusion As Kubernetes environments continue to expand, the need for consistent, secure, and efficient multi‑cluster application delivery becomes increasingly critical. Together, F5 BIG‑IP CIS and Nutanix Kubernetes Platform (NKP) provide a unified, automated, and future‑ready solution that removes much of the operational complexity traditionally associated with distributed architectures. This joint solution delivers consistent security enforcement, intelligent traffic management, and streamlined operations across any number of Kubernetes clusters. Whether an organization is aimed at modernization, expanding into multi‑cluster architectures, or working to streamline and secure Kubernetes traffic flows, F5 and Nutanix jointly offer a forward-looking path. Multi‑cluster Kubernetes doesn’t have to be complex—and with F5 BIG‑IP CIS and Nutanix Kubernetes Platform (NKP), it’s never been simpler. Related URLs F5 BIG-IP Container Ingress Services (CIS) for Multi-Cluster https://clouddocs.f5.com/containers/latest/userguide/multicluster/ Nutanix Kubernetes Platform (NKP) https://www.nutanix.com/products/kubernetes-management-platform
91Views2likes0CommentsIdentity-centric F5 ADSP Integration Walkthrough
In this article we explore F5 ADSP from the Identity lense by using BIG-IP APM, BIG-IP SSLO and add BIG-IP AWAF to the service chain. The F5 ADSP addresses four core areas: Deployment at scale, Security against evolving threats, Deliver application reliably, Operate your day to day work efficiently. Each comes with its own challenges, but together they define the foundation for keeping systems fast, stable, and safe. Each architecture deployment example is designed to cover at least two of the four core areas: Deployment, Security, Delivery and XOps.254Views3likes0CommentsBIG-IP Next for Kubernetes CNFs - DNS walkthrough
Introduction F5 enables advanced DNS implementations across different deployments, whether it’s hardware, Virtual Functions and F5 Distributed Cloud. Also, in Kubernetes environment through the F5BigDnsApp Custom Resource Definition (CRD), allowing declarative configuration of DNS listeners, pools, monitors, and profiles directly in-cluster. Deploying DNS services like Express, Cache, and DoH within the Kubernetes cluster using BIG-IP Next for Kubernetes CNF DNS saves external traffic by resolving queries locally (reducing egress to upstream resolvers by up to 80% with caching) and enhances security through in-cluster isolation, mTLS enforcement, and protocol encryption like DoH, preventing plaintext DNS exposure over cluster boundaries. This article provides a walkthrough for DNS Express, DNS Cache, and DNS-over-HTTPS (DoH) on top of Red Hat OpenShift. Prerequisites Deploy BIG-IP Next for Kubernetes CNF following the steps in F5’s Cloud-Native Network Functions (CNFs) Verify the nodes and CNF components are installed [cloud-user@ocp-provisioner f5-cne-2.1.0]$ kubectl get nodes NAME STATUS ROLES AGE VERSION master-1.ocp.f5-udf.com Ready control-plane,master,worker 2y221d v1.29.8+f10c92d master-2.ocp.f5-udf.com Ready control-plane,master,worker 2y221d v1.29.8+f10c92d master-3.ocp.f5-udf.com Ready control-plane,master,worker 2y221d v1.29.8+f10c92d worker-1.ocp.f5-udf.com Ready worker 2y221d v1.29.8+f10c92d worker-2.ocp.f5-udf.com Ready worker 2y221d v1.29.8+f10c92d [cloud-user@ocp-provisioner f5-cne-2.1.0]$ kubectl get pods -n cne-core NAME READY STATUS RESTARTS AGE f5-cert-manager-656b6db84f-dmv78 2/2 Running 10 (15h ago) 19d f5-cert-manager-cainjector-5cd9454d6c-sc8q2 1/1 Running 21 (15h ago) 19d f5-cert-manager-webhook-6d87b5797b-954v6 1/1 Running 4 19d f5-dssm-db-0 3/3 Running 13 (18h ago) 15d f5-dssm-db-1 3/3 Running 0 18h f5-dssm-db-2 3/3 Running 4 (18h ago) 42h f5-dssm-sentinel-0 3/3 Running 0 14h f5-dssm-sentinel-1 3/3 Running 10 (18h ago) 5d8h f5-dssm-sentinel-2 3/3 Running 0 18h f5-rabbit-64c984d4c6-xn2z4 2/2 Running 8 19d f5-spk-cwc-77d487f955-j5pp4 2/2 Running 9 19d [cloud-user@ocp-provisioner f5-cne-2.1.0]$ kubectl get pods -n cnf-fw-01 NAME READY STATUS RESTARTS AGE f5-afm-76c7d76fff-5gdhx 2/2 Running 2 42h f5-downloader-657b7fc749-vxm8l 2/2 Running 0 26h f5-dwbld-d858c485b-6xfq8 2/2 Running 2 26h f5-ipsd-79f97fdb9c-zfqxk 2/2 Running 2 26h f5-tmm-6f799f8f49-lfhnd 5/5 Running 0 18h f5-zxfrd-d9db549c4-6r4wz 2/2 Running 2 (18h ago) 26h f5ingress-f5ingress-7bcc94b9c8-zhldm 5/5 Running 6 26h otel-collector-75cd944bcc-xnwth 1/1 Running 1 42h DNS Express Walkthrough DNS Express configures BIG-IP to authoritatively answer queries for a zone by pulling it via AXFR/IXFR from an upstream server, with optional TSIG auth keeping zone data in-cluster for low-latency authoritative resolution. Step 1: Create a F5BigDnsZone CR for zone transfer (e.g., example.com from upstream 10.1.1.12). # cat 10-cr-dnsxzone.yaml apiVersion: k8s.f5net.com/v1 kind: F5BigDnsZone metadata: name: example.com spec: dnsxAllowNotifyFrom: ["10.1.1.12"] dnsxServer: address: "10.1.1.12" port: 53 dnsxEnabled: true dnsxNotifyAction: consume dnsxVerifyNotifyTsig: false #kubectl apply -f 10-cr-dnsxzone.yaml -n cnf-fw-01 Step 2: Deploy F5BigDnsApp CR with DNS Express enabled # cat 11-cr-dnsx-app-udp.yaml apiVersion: "k8s.f5net.com/v1" kind: F5BigDnsApp metadata: name: "dnsx-app-listener" namespace: "cnf-fw-01" spec: destination: address: "10.1.30.100" port: 53 ipProtocol: "udp" snat: type: "automap" dns: dnsExpressEnabled: true logProfile: "cnf-log-profile" # kubectl apply -f 11-cr-dnsx-app-udp.yaml -n cnf-fw-01 Step 3: Validate: Query from our client pod & tmm statistics dig @10.1.30.100 www.example.com ; <<>> DiG 9.18.30-0ubuntu0.20.04.2-Ubuntu <<>> @10.1.30.100 www.example.com ; (1 server found) ;; global options: +cmd ;; Got answer: ;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 43865 ;; flags: qr aa rd; QUERY: 1, ANSWER: 1, AUTHORITY: 1, ADDITIONAL: 2 ;; WARNING: recursion requested but not available ;; OPT PSEUDOSECTION: ; EDNS: version: 0, flags:; udp: 4096 ;; QUESTION SECTION: ;www.example.com. IN A ;; ANSWER SECTION: www.example.com. 604800 IN A 192.168.1.11 ;; AUTHORITY SECTION: example.com. 604800 IN NS ns.example.com. ;; ADDITIONAL SECTION: ns.example.com. 604800 IN A 192.168.1.10 ;; Query time: 0 msec ;; SERVER: 10.1.30.100#53(10.1.30.100) (UDP) ;; WHEN: Thu Jan 22 11:10:24 UTC 2026 ;; MSG SIZE rcvd: 93 kubectl exec -it deploy/f5-tmm -c debug -n cnf-fw-01 -- bash /tmctl -id blade tmmdns_zone_stat name=example.com name dnsx_queries dnsx_responses dnsx_xfr_msgs dnsx_notifies_recv ----------- ------------ -------------- ------------- ------------------ example.com 2 2 0 0 DNS Cache Walkthrough DNS Cache reduces latency by storing responses non-authoritatively, referenced via a separate cache CR in the DNS profile, cutting repeated upstream queries and external bandwidth use. Step 1: Create a DNS Cache CR F5BigDnsCache # cat 13-cr-dnscache.yaml apiVersion: "k8s.f5net.com/v1" kind: F5BigDnsCache metadata: name: "cnf-dnscache" spec: cacheType: resolver resolver: useIpv4: true useTcp: false useIpv6: false forwardZones: - forwardZone: "example.com" nameServers: - ipAddress: 10.1.1.12 port: 53 - forwardZone: "." nameServers: - ipAddress: 8.8.8.8 port: 53 # kubectl apply -f 13-cr-dnscache.yaml -n cnf-fw-01 Step 2: Deploy F5BigDnsApp CR with DNS Cache enabled # cat 11-cr-dnsx-app-udp.yaml apiVersion: "k8s.f5net.com/v1" kind: F5BigDnsApp metadata: name: "dnsx-app-listener" namespace: "cnf-fw-01" spec: destination: address: "10.1.30.100" port: 53 ipProtocol: "udp" snat: type: "automap" dns: dnsCache: "cnf-dnscache" logProfile: "cnf-log-profile" # kubectl apply -f 11-cr-dnsx-app-udp.yaml -n cnf-fw-01 Step 3: Validate: Query from our client pod dig @10.1.30.100 www.example.com ; <<>> DiG 9.18.30-0ubuntu0.20.04.2-Ubuntu <<>> @10.1.30.100 www.example.com ; (1 server found) ;; global options: +cmd ;; Got answer: ;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 18302 ;; flags: qr rd ra; QUERY: 1, ANSWER: 1, AUTHORITY: 0, ADDITIONAL: 1 ;; OPT PSEUDOSECTION: ; EDNS: version: 0, flags:; udp: 4096 ;; QUESTION SECTION: ;www.example.com. IN A ;; ANSWER SECTION: www.example.com. 19076 IN A 192.168.1.11 ;; Query time: 4 msec ;; SERVER: 10.1.30.100#53(10.1.30.100) (UDP) ;; WHEN: Thu Jan 22 11:04:45 UTC 2026 ;; MSG SIZE rcvd: 60 DoH Walkthrough DoH exposes DNS over HTTPS (port 443) for encrypted queries, using BIG-IP's protocol inspection and UDP profiles, securing in-cluster DNS from eavesdropping and MITM attacks. Step 1: Ensure TLS secret exists and HTTP profiles exist # cat 14-tls-clientsslsettings.yaml apiVersion: k8s.f5net.com/v1 kind: F5BigClientsslSetting metadata: name: "cnf-clientssl-profile" namespace: "cnf-fw-01" spec: enableTls13: true enableRenegotiation: false renegotiationMode: "require" # cat 15-http-profiles.yaml apiVersion: "k8s.f5net.com/v1" kind: F5BigHttp2Setting metadata: name: http2-profile spec: activationModes: "alpn" concurrentStreamsPerConnection: 10 connectionIdleTimeout: 300 frameSize: 2048 insertHeader: false insertHeaderName: "X-HTTP2" receiveWindow: 32 writeSize: 16384 headerTableSize: 4096 enforceTlsRequirements: true --- apiVersion: "k8s.f5net.com/v1" kind: F5BigHttpSetting metadata: name: http-profile spec: oneConnect: false responseChunking: "sustain" lwsMaxColumn: 80 # kubectl apply -f 14-tls-clientsslsettings.yaml -n cnf-fw-01 # kubectl apply -f 15-http-profiles.yaml -n cnf-fw-01 Step 2: Create DNSApp for DoH service # cat 16-DNSApp-doh.yaml apiVersion: "k8s.f5net.com/v1" kind: F5BigDnsApp metadata: name: "cnf-dohapp" namespace: "cnf-fw-01" spec: ipProtocol: "udp" dohProtocol: "udp" destination: address: "10.1.20.100" port: 443 snat: type: "automap" dns: dnsExpressEnabled: false dnsCache: "cnf-dnscache" clientSslSettings: "clientssl-profile" pool: members: - address: "10.1.10.50" monitors: dns: enabled: true queryName: "www.example.com" queryType: "a" recv: "192.168.1.11" # kubectl apply -f 16-DNSApp-doh.yaml -n cnf-fw-01 Step 3: Testing from our client pod ubuntu@client:~$ dig @10.1.20.100 -p 443 +https +notls-ca www.google.com ; <<>> DiG 9.18.30-0ubuntu0.20.04.2-Ubuntu <<>> @10.1.20.100 -p 443 +https +notls-ca www.google.com ; (1 server found) ;; global options: +cmd ;; Got answer: ;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 4935 ;; flags: qr rd ra; QUERY: 1, ANSWER: 6, AUTHORITY: 0, ADDITIONAL: 1 ;; OPT PSEUDOSECTION: ; EDNS: version: 0, flags:; udp: 4096 ;; QUESTION SECTION: ;www.google.com. IN A ;; ANSWER SECTION: www.google.com. 69 IN A 142.251.188.103 www.google.com. 69 IN A 142.251.188.147 www.google.com. 69 IN A 142.251.188.106 www.google.com. 69 IN A 142.251.188.105 www.google.com. 69 IN A 142.251.188.99 www.google.com. 69 IN A 142.251.188.104 ;; Query time: 8 msec ;; SERVER: 10.1.20.100#443(10.1.20.100) (HTTPS) ;; WHEN: Thu Jan 22 11:27:05 UTC 2026 ;; MSG SIZE rcvd: 139 ubuntu@client:~$ dig @10.1.20.100 -p 443 +https +notls-ca www.example.com ; <<>> DiG 9.18.30-0ubuntu0.20.04.2-Ubuntu <<>> @10.1.20.100 -p 443 +https +notls-ca www.example.com ; (1 server found) ;; global options: +cmd ;; Got answer: ;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 20401 ;; flags: qr rd ra; QUERY: 1, ANSWER: 1, AUTHORITY: 0, ADDITIONAL: 1 ;; OPT PSEUDOSECTION: ; EDNS: version: 0, flags:; udp: 4096 ;; QUESTION SECTION: ;www.example.com. IN A ;; ANSWER SECTION: www.example.com. 17723 IN A 192.168.1.11 ;; Query time: 4 msec ;; SERVER: 10.1.20.100#443(10.1.20.100) (HTTPS) ;; WHEN: Thu Jan 22 11:27:18 UTC 2026 ;; MSG SIZE rcvd: 60 Conclusion BIG-IP Next DNS CRs transform Kubernetes into a production-grade DNS platform, delivering authoritative resolution, caching efficiency, and encrypted DoH, all while optimizing external traffic costs and hardening security boundaries for cloud-native deployments. Related Content BIG-IP Next for Kubernetes CNF guide BIG-IP Next Cloud-Native Network Functions (CNFs) BIG-IP Next for Kubernetes CNF deployment walkthrough BIG-IP Next Edge Firewall CNF for Edge workloads | DevCentral Modern Applications-Demystifying Ingress solutions flavors | DevCentral79Views2likes0CommentsDelivering Secure Application Services Anywhere with Nutanix Flow and F5 Distributed Cloud
Introduction F5 Application Delivery and Security Platform (ADSP) is the premier solution for converging high-performance delivery and security for every app and API across any environment. It provides a unified platform offering granular visibility, streamlined operations, and AI-driven insights — deployable anywhere and in any form factor. The F5 ADSP Partner Ecosystem brings together a broad range of partners to deliver customer value across the entire lifecycle. This includes cohesive solutions, cloud synergies, and access to expert services that help customers maximize outcomes while simplifying operations. In this article, we’ll explore the upcoming integration between Nutanix Flow and F5 Distributed Cloud, showcasing how F5 and Nutanix collaborate to deliver secure, resilient application services across hybrid and multi-cloud environments. Integration Overview At the heart of this integration is the capability to deploy a F5 Distributed Cloud Customer Edge (CE) inside a Nutanix Flow VPC, establish BGP peering with the Nutanix Flow BGP Gateway, and inject CE-advertised BGP routes into the VPC routing table. This architecture provides us complete control over application delivery and security within the VPC. We can selectively advertise HTTP load balancers (LBs) or VIPs to designated VPCs, ensuring secure and efficient connectivity. Additionally, the integration securely simplifies network segmentation across hybrid and multi-cloud environments. By leveraging F5 Distributed Cloud to segment and extend the network to remote locations, combined with Nutanix Flow Security for microsegmentation within VPCs, we deliver comprehensive end-to-end network security. This approach enforces a consistent security posture while simplifying segmentation across environments. In this article, we’ll focus on application delivery and security, and explore segmentation in the next article. Demo Walkthrough Let’s walk through a demo to see how this integration works. The goal of this demo is to enable secure application delivery for nutanix5.f5-demo.com within the Nutanix Flow Virtual Private Cloud (VPC) named dev3. Our demo environment, dev3, is a Nutanix Flow VPC with a F5 Distributed Cloud Customer Edge (CE) named jy-nutanix-overlay-dev3 deployed inside: *Note: CE is named jy-nutanix-overlay-dev3 in the F5 Distributed Cloud Console and xc-ce-dev3 in the Nutanix Prism Central. eBGP peering is ESTABLISHED between the CE and the Nutanix Flow BGP Gateway: On the F5 Distributed Cloud Console, we created an HTTP Load Balancer named jy-nutanix-internal-5 serving the FQDN nutanix5.f5-demo.com. This load balancer distributes workloads across hybrid multicloud environments and is protected by a WAF policy named nutanix-demo: We advertised this HTTP Load Balancer with a Virtual IP (VIP) 10.10.111.175 to the CE jy-nutanix-overlay-dev3 deployed inside Nutanix Flow VPC dev3: The CE then advertised the VIP route to its peer via BGP – the Nutanix Flow BGP Gateway: The Nutanix Flow BGP Gateway received the VIP route and installed it in the VPC routing table: Finally, the VMs in dev3 can securely access nutanix5.f5-demo.com while continuing to use the VPC logical router as their default gateway: F5 Distributed Cloud Console observability provides deep visibility into applications and security events. For example, it offers comprehensive dashboards and metrics to monitor the performance and health of applications served through HTTP load balancers. These include detailed insights into traffic patterns, latency, HTTP error rates, and the status of backend services: Furthermore, the built-in AI assistant provides real-time visibility and actionable guidance on security incidents, improving situational awareness and supporting informed decision-making. This capability enables rapid threat detection and response, helping maintain a strong and resilient security posture: Conclusion The integration demonstrates how F5 Distributed Cloud and Nutanix Flow collaborate to deliver secure, resilient application services across hybrid and multi-cloud environments. Together, F5 and Nutanix enable organizations to scale with confidence, optimize application performance, and maintain robust security—empowering businesses to achieve greater agility and resilience across any environment. This integration is coming soon in CY2026. If you’re interested in early access, please contact your F5 representative. Related URLs Simplifying and Securing Network Segmentation with F5 Distributed Cloud and Nutanix Flow | DevCentral F5 Distributed Cloud - https://www.f5.com/products/distributed-cloud-services Nutanix Flow Virtual Networking - https://www.nutanix.com/products/flow/networking
166Views1like0Comments
