NimbostratusR series - Host and Tenants IP in the same subnet
Hi,
Can i have the host F5OS and tenant IP in the same subnet. Exaple:
Host: 10.10.1.10/24
Tenant IP: 10.10.1.200/24
Is that possible or anything to keep in mind
7 Replies
- Juergen_Mang
MVP
The management IPs of F5OS and tenants must be in the same subnet, as they share the same management connection.
SuppEsp_AXYou mean they share same MGMT interface although they have two diferents IPs in the same subnet. right?
- Juergen_Mang
correct
mplaksin1Hello. It is correct to have both on the same network; normally the management network.
- SuppEsp_AX
Being reached in the MGMT port, right?
- mplaksin1
Yes , for managment purporses you have to connect de MGMT port and assign a managment IP to any component:
- Anoop_Jayadharan
Cirrostratus
Hey SuppEsp_AX
Not sure if I am late to reply.
Basically, the Management port in the rSeries is bridged, so the same network configured on the host is accessible for tenants if set up correctly. The concept remains the same as the vCMP/Viprion models.
You may use one more IP address from the pool for the AOM if you wish to
