Forum Discussion

redadmin1972's avatar
redadmin1972
Icon for Altocumulus rankAltocumulus
Apr 10, 2024
Solved

Pool round Robin not working with standard virtual server

I have a standard HTTPS virtual server configured with two nodes in the pool. There is no persistence setting enabled and the load balancing method is round robin. For some reason, after I browse to...
load balance
persistence
pool member
round robin
  • Paulius's avatar
    Paulius
    Apr 11, 2024

    The reason you're having this issue is most likely because of the following entry in your iRule.



    catch { persist uie [HTTP::header "X-Forwarded-For"] 1800 }



    That entry will always apply UIE persistence based on the HTTP header "X-Forwarded-For" so you then get bound to the same pool member all the time.

Paulius's avatar
Paulius
Icon for MVP rankMVP
Apr 10, 2024

redadmin1972 Would you be able to provide the CLI output for the virtual server and any associated configuration such as pools, profiles, and irules?

redadmin1972's avatar
redadmin1972
Icon for Altocumulus rankAltocumulus
Apr 11, 2024

Here is CLI output for the virtual server



From NonProd LTM:

ltm virtual website_https_vs {
    creation-time 2021-02-19:02:17:10
    destination 10.0.0.10:https
    ip-protocol tcp
    last-modified-time 2021-10-05:14:48:44
    mask 255.255.255.255
    pool website_https_pool
    profiles {
        website_SSL {
            context clientside
        }
        http { }
        serverssl {
            context serverside
        }
        tcp { }
    }
    rules {
        DEFAULT-IR
    }
    serverssl-use-sni disabled
    source 0.0.0.0/0
    source-address-translation {
        type automap
    }
    translate-address enabled
    translate-port enabled
    vs-index 64
}



Here is the iRule DEFAULT-IR

when HTTP_REQUEST {
    if {not([HTTP::header exists "X-Forwarded-For"])} {
        HTTP::header insert X-Forwarded-For [IP::remote_addr]
    }
    catch { persist uie [HTTP::header "X-Forwarded-For"] 1800 }
}



No policies are applied



Standard HTTPS pool with two ephemeral nodes from FQDN lookup. Load balancing method is Round Robin and Priority Group Activation is Disabled
