Synchronize device_trust_group

I've recently performed an upgrade of an active/standby LTM device group. I moved from 11.2 to 11.4 in order to test the upgrade path for the new version.

Upon upgrade of 11.4 of the standby and reboot, I got the following error in 'Device Management ›› Device Trust : Local Domain'.

Synchronize /Common/bigip1.innova.local to group /Common/device_trust_group

This prevents config sync of the two devices as well as failover between the two devices. I've done plenty of research on this error and I can't get this fixed. Specifically, I followed all the DSC troubleshooting steps and even reset the Device Trust on both devices in the group.

ref: https://support.f5.com/kb/en-us/solutions/public/13000/900/sol13946.htmlcso

3 Replies

  • Kevin_K_51432's avatar
    Kevin_K_51432
    Historic F5 Account

    Greetings Chris, There aren't that many moving parts with the device trust, probably a timing difference either with the systems OR the system times are fine, but the SSL certificates were created when the systems times were off. Can you 1) ensure NTP is setup and connecting to the remove server (SOL10240: Verifying NTP peer server communications) and when resetting device trust, "Generate new self-signed authority". Lastly, re-join the devices?



    Hope this helps, Kevin



  • Yesterday, I did notice a difference in time when attempting to rejoin the devices. NTP settings were all correct and funtioning, so I forced a time sync with

    ntpdate -s
    on both devices. Afterwards and again just now I also reset the device trust as follows:

    • Reset Device Trust, using 'Generate new self-signed authority' on both devices
    • Add peer to each device.

    And now I get a new error on config sync, which looks to be more problematic:

    Decryption of the field (bind_pw) for object (system-auth) failed

    Upon checking the master key with

    f5mku -K
    the keys are different. Furthermore, if I try to sync them manually, by resetting I get this error:

    f5mku -r
    Rekeying Master Key...
    Error trying to rekey: 01071029:5: master_decrypt failed during rekey
