DevCentral Connects Recap: Open Finance, APIs, AI & Security
In this DevCentral Connects recap we chat about the Global State of Open Finance report and the industry’s shift from open banking to broader open finance. We cover the security implications as APIs proliferate (including shadow APIs), how AI is reshaping risk and opportunity, and practical steps for teams—API discovery, centralized enforcement, least‑privilege, and model governance. Watch the full conversation hereSimplifying API Security with New Jira Integration and F5 Distributed Cloud
Introduction APIs fuel modern applications—but as they scale, grow, and evolve, API sprawl becomes a serious concern for security and operations teams. That’s where F5 Distributed Cloud API Discovery comes into play: enabling deep visibility into all your APIs, whether managed or unmanaged. And now, with our new integration with Jira, API lifecycle management just got a whole lot easier. API Discovery - The foundation of API Security Before you can protect or govern your APIs, you need to know what exists. F5 Distributed Cloud API Discovery continuously scans your environments (including ingress gateways and services) to automatically detect, catalog, and classify APIs—including shadow APIs and zombie endpoints you may not even know exist. This forms the foundation for API Security, Governance, and Compliance. But discovering APIs is only the first step. You still need to triage findings, prioritize action, and loop in the right teams to fix or respond. Introducing Jira Ticketing Integration With the new Jira integration, customers can now seamlessly push API discovery security posture findings into their ticketing and workflow systems. This accelerates remediation, reducing silos, and enabling true DevSecOps collaboration. Key capabilities: Automatic ticket creation from F5 Distributed Cloud API Security to Jira’s ticketing system for the vulnerabilities discovered Detailed context embedded in Jira ticket - API endpoint, Base Path, API Category, Authentication status, vulnerability details, risk score and suggested remediation actions Assign to Teams based on API owner, service or environment This helps security and platform teams shift left while giving development teams better context to secure their APIs. Pre-requisites You need to have Jira Service Management (SaaS) tenant and account Distributed Cloud Tenant 1. Jira Service Management Account (SaaS) 2. Create a project (In this example: project name is "F5") 3. Generate API Token to allow F5 Distributed Cloud to communicate with Jira Make sure of the expiration date of this API token - API token should be valid for the communication between F5 Distributed Cloud and Jira 4. In F5 Distributed Cloud Tenant, Create new ticket tracking system object with Jira details (Shared Configuration Tile -> Manage -> Ticket Tracking System) It requires to fill "API Token", "Jira Account Email" and "Jira Organization Domain" 5. Under API Endpoint Dashboard, find the relevant API Endpoint you need to trigger Jira Ticket (API Endpoint -> Security Posture -> relevant API vulnerability -> Create Ticket) Ticket will be created automatically in Jira and then you can assign it to one of the team members. It could be service owner or API owner You can also review the ticket in F5 API Endpoint Security Posture with direct link to Jira ticket Summary Too often, API security tools operate in silos, separate from the developer and operations workflows. This integration bridges that gap, enabling: DevOps-friendly workflows Faster MTTR (mean time to remediation) Better cross-team visibility Automated compliance tracking By turning API discovery insights into actionable tasks, organizations can better manage risk and reduce operational overhead.Technical Impacts of Open Banking and Financial Data Exchange on Financial Systems
Determine your baseline requirements and dissect essential compliance requirements in Open Banking. Discuss with the DevCentral community to dissect gap analysis to prepare security and platform teams to build plans for safely deploying digital first financial services.Mitigating OWASP 2023 API Security Top 10 Risks Using F5 NGINX App Protect
The OWASP API Security Top 10 highlights the most critical security risks facing APIs, as a global standard for understanding and mitigating vulnerabilities. Based on extensive data analysis and community contributions, the list identifies prevalent vulnerabilities specific to the unique attack surface of APIs. The 2023 edition introduces new vulnerabilities like Unrestricted Access to Sensitive Business Flows, Server-Side Request Forgery, Unsafe Consumption of APIs and highlights emerging threats related to modern API architectures and integrations. For detailed information, please visit: OWASP API Security Top 10 - 2023. F5 products provide essential controls to secure APIs against these specific risks. F5 NGINX App Protect delivers comprehensive API security capabilities, employing both positive and negative security models. The positive security model validates API requests against defined schemas (like Open API) and enforces strict data formats, while the negative security model uses updated signatures to detect and block known API attack patterns and OWASP API Top 10 threats, including injection flaws and improper asset management. This guide outlines how to configure and implement effective protection for your APIs based on their specific requirements and the risks identified in the OWASP API Security Top 10. Note: The OWASP risks below are successfully tested on both NGINX App Protect Version 4 and Version 5. The set up and configurations for both the Versions are different. To bring up the setup for NGINX Version 5, follow the below links: https://docs.nginx.com/nginx-app-protect-waf/v5/admin-guide/install/ https://docs.nginx.com/nginx-app-protect-waf/v5/admin-guide/compiler/ API2:2023 – Broken Authentication Broken Authentication is a vulnerability that refers to incorrectly implemented authentication mechanisms or session management for APIs. Attackers exploit these flaws (like weak credentials, flawed token validation, or missing checks) to impersonate legitimate users and gain unauthorized access to data or functionality. Problem Statement: Broken Authentication is a big risk to API security. It happens when problems with the API’s identity verification process let attackers get around the authentication mechanisms. Successful exploitation leads attackers to impersonate legitimate users, gain unauthorized access to sensitive data, perform actions on behalf of victims, and potentially take over accounts or systems. This demonstration uses the Damn Vulnerable Web Application (DVWA) to show the exploitability of Broken Authentication. We will execute a brute-force attack against the login interface, iterating through potential credential pairs to achieve unauthorized authentication. Below is the selenium automated script to execute a brute-force attack, submitting multiple credential combinations to attempt authentication. The brute-force attack successfully compromised authentication controls by iterating through multiple credential pairs, ultimately granting access. Solution: To mitigate the above vulnerability, NGINX App Protect is deployed and configured as a reverse proxy in front of the application, and NAP first validates requests for the vulnerabilities. The NGINX App Protect Brute Force WAF policy is utilized as shown below. Re-attempt to gain access to the application using the brute-force approach is rejected and blocked. Support ID verification in the Security logs shows request is blocked because of Brute Force Policy. API3:2023 – Broken Object Property Level Authorization Broken Object Property Level Authorization is a key vulnerability listed that occurs when an API fails to properly validate if the current user has permission to access or modify specific fields (properties) within an object. This can lead to unauthorized data exposure or modification, even if the user has access to the object itself. This category combines API3: 2019 - Excessive Data Exposure and API6: 2019 - Mass Assignment. Excessive Data Exposure Problem Statement: A critical API security risk, Broken Authentication occurs when weaknesses in the API's identity verification process permit attackers to circumvent authentication mechanisms. Successful exploitation leads attackers to impersonate legitimate users, gain unauthorized access to sensitive data, perform actions on behalf of victims, and potentially take over accounts or systems. Solution: To prevent this vulnerability, we will use the DataGuard feature in NGINX App Protect, which validates all response data for sensitive details and will either mask the data or block those requests, as per the configured settings. First, we will configure DataGuard to mask the PII data as shown below and will apply this configuration. dataguard_blocking WAF Policy Next, if we resend the same request, we can see that the CCN/SSN numbers are masked, thereby preventing data breaches. If needed, we can update configurations to block this vulnerability, after which all incoming requests for this endpoint will be blocked. Fig: The request is blocked when block mode in blocking_settings is "true" If you open the security log and filter with this support ID, we can see that the request is either blocked or PII data is masked, as per the DataGuard configuration applied in the above section. Mass Assignment Problem Statement: API Mass Assignment vulnerability arises when clients can modify immutable internal object properties via crafted requests, bypassing API Endpoint restrictions. Attackers exploit this by sending malicious HTTP requests to escalate privileges, bypass security mechanisms, or manipulate the API Endpoint's functionality. Placing an order with quantity as 1: Bypassing API Endpoint restrictions and placing the order with quantity as -1 is also successful. Solution: To overcome this vulnerability, we will use the WAF API Security Policy in NGINX App Protect which validates all the API Security events triggered and based on the enforcement mode set in the validation rules, the request will either get reported or blocked, as shown below. Restricted/updated swagger file with .json extension is added as below: api.json file is updated with minimum Product Quantity Policy used: App Protect API Security Re-attempting to place the order with quantity as -1 is getting blocked. Attempt to place order with product count as -1 Validating the support ID in Security log as below: API4:2023 – Unrestricted Resource Consumption Unrestricted Resource Consumption refers to APIs that don't adequately limit the resources (e.g., CPU, memory, network bandwidth) a client can request or utilize. This can lead to performance degradation or Denial of Service (DoS) attacks, impacting availability for all users and potentially increasing operational costs significantly. Lack of Resources and Rate-Limiting Problem Statement: APIs do not have any restrictions on the size or number of resources that can be requested by the end user. The above-mentioned scenarios sometimes lead to poor API server performance, Denial of Service (DoS), and brute-force attacks. Solution: NGINX App Protect provides different ways to rate-limit the requests as per user requirements. A simple rate-limiting use case configuration can block requests after reaching the limit, which is demonstrated below. API6:2023 – Unrestricted Access to Sensitive Business Flows When an API lets people perform key business actions too easily without limits, attackers can automate abuse. This might mean hoarding products, causing financial damage, or spamming, giving them an unfair advantage. Problem Statement: Within the product purchasing flow, a critical vulnerability allows an attacker to execute a rapid, large-scale acquisition. They target a high-demand product, bypassing any intended quantity limits, and effectively corner the market by buying out the complete stock in one swift operation. This leaves genuine buyers frustrated and empty-handed, while the attacker capitalizes on the artificially created scarcity by reselling the goods at a steep markup. Below is the checkout POST call for the product. Below is the Python script to generate product checkout in bulk; provided quantity as 9999. Script to generate bulk product checkout requests Solution: The above vulnerability can be prevented using NGINX App Protect Bot Defense WAF Policy, which is blocking the bulk bot-generated product checkout request using the malicious script. Requests sent to check out the product using the above selenium script are blocked successfully as shown below. Bot request for bulk order is blocked Validating the support ID in Security log as below: Request captured in NGINX App Protect security log API7:2023 – Server-Side Request Forgery A new entrant to the OWASP API Security Top 10 in 2023, Server-Side Request Forgery (SSRF) vulnerabilities occur when an API fetches a remote resource (like a URL) without properly validating the user-supplied destination. Attackers exploit this by tricking the API into sending crafted requests to the server itself, leading to information disclosure or interaction with sensitive backend services. Problem Statement: Within the product purchasing flow, a critical vulnerability allows an attacker to execute a rapid, large-scale acquisition. They target a popular product, going past any planned limits, and effectively control the market by buying all the stock in one quick move. This makes real buyers angry and empty-handed, while the attacker makes money from the fake shortage by reselling the goods at a high price. In the application below, click on ‘Contact Mechanic’ and provide required details like Mechanic name, Problem Description and send Service Request. Contact Mechanic Request Payload Below image shows that ‘contact_mechanic’ endpoint is internally making a call to ‘mechanic_api’ URL. Since ‘mechanic_api’ parameter accepts URL as data, this can be vulnerable to SSRF attacks. Exploiting the vulnerable endpoint by modifying ‘mechanic_api’ URL call to www.google.com in POST data call got accepted by returning 200 OK as response. This vulnerability can be misused to gain access to internal resources. POST Call with incorrect mechanic_api endpoint in request body Solution: To prevent this vulnerability, we will use the WAF API Security Policy in NGINX App Protect, which validates all the API request parameters and will block the suspicious requests consisting of irrelevant parameters, as shown below. Restricted/updated swagger file with .json extension is added as below: Updated the Swagger file with restricted pattern for mechanic_api endpoint Policy used: App Protect API Security API Security Policy Retrying the vulnerability with ‘mechanic_api’ URL call to www.google.com in POST data now getting blocked. mechanic_api endpoint in request body Validating the support ID in the security log below: API8:2023 – Security Misconfiguration Security problems happen when people don’t follow security best practices. This can lead to problems like open debug logs, old security patches, wrong CORS settings, and unnecessary allowed HTTP methods. To prevent this, systems must stay up to date with security patches, employ continuous hardening, ensure API communications use secure channels (TLS), etc. Problem Statement: Unnecessary HTTP methods/verbs represent a significant security misconfiguration under the OWASP API Top 10. APIs often reveal a range of HTTP methods (such as PUT, DELETE, PATCH) that are not required for the application's functionality. These unused methods, if not properly disabled, can provide attackers with additional attack surfaces, increasing the risk of unauthorized access or unintended actions on the server. Properly limiting and configuring allowed HTTP methods is essential for reducing the potential impact of such security vulnerabilities. Let’s dive into a demo application which has exposed “PUT” method., this method is not required as per the design and attackers can make use of this insecure, unintended method to modify the original content. modified using PUT method Solution: NGINX App Protect makes it easy to block unnecessary or risky HTTP methods by letting you customize which methods are allowed. By easily configuring a policy to block unauthorized methods, like disabling the PUT method by setting "$action": "delete", you can reduce potential security risks and strengthen your API protection with minimal effort. As shown below, the attack request is captured in security log, which conveys the request was successfully blocked because of “Illegal method” violation. API9:2023 – Improper Inventory Management Improper Asset Management in API security signifies the crucial risk stemming from an incomplete awareness and tracking of an organization’s full API landscape, including all environments like development and staging, different versions, both internal and external endpoints, and undocumented or "shadow" APIs. This lack of comprehensive inventory leads to an expanded and often unprotected attack surface, as security measures cannot be consistently applied to unknown or unmanaged assets. Consequently, attackers can exploit these overlooked endpoints, potentially find older, less secure versions or access sensitive data inadvertently exposed in non-production environments, thereby undermining overall security posture because you simply cannot protect assets you don't know exist. Problem Statement: APIs do not have any restrictions on the size or number of resources that can be requested by the end user. The above-mentioned scenarios sometimes lead to poor API server performance, Denial of Service (DoS), and brute-force attacks. We’re using a flask database application with multiple API endpoints for demonstration. As part of managing API assets, the “/v1/admin/users” endpoint in the demo Flask application has been identified as obsolete. The continued exposure of the deprecated “/v1/admin/users” endpoint constitutes an Improper Asset Management vulnerability, creating an unnecessary security exposure that could be used for exploitation. <public_ip>/v1/admin/users The current endpoint for user listing is “/v2/users”. <public_ip>/v2/users with user as admin1 Solution: To mitigate the above vulnerability, we are using NGINX as an API Gateway. The API Gateway acts as a filtering gateway for API incoming traffic, controlling, securing, and routing requests before they reach the backend services. The server’s name used for the above case is “f1-api” which is listening to the public IP where our application is running. To query the “/v1/admin/users” endpoint, use the curl command as shown below. Below is the configuration for NGINX as API Gateway, in “api_gateway.conf”, where “/v1/admin/users” endpoint is deprecated. api_gateway.conf The “api_json_errors.conf” is configured with error responses as shown below and included in the above “api_gateway.conf”. api_json_errors.conf Executing the curl command against the endpoint yields an “HTTP 301 Moved Permanently” response. https://f1-api/v1/admin/users is deprecated Conclusion: This article explains the OWASP 2023 Top 10 API security risks. It also shows how NGINX App Protect can be used to stop these OWASP API security risks. Related resources for more information or to get started: F5 NGINX App Protect OWASP API Security Top 10 2023OWASP Tactical Access Defense Series: Broken Object Property Level Authorization and BIG-IP APM
AUTHOR NOTE: Unauthorized access to private/sensitive object properties may result in data disclosure, data loss, or data corruption. Under certain circumstances, unauthorized access to object properties can lead to privilege escalation or partial/full account takeover. In this article we are going through API3 item from OWASP top 10 API Security risks exploring BIG-IP Access Policy Manager (APM) role in our arsenal. Identifying Vulnerable APIs In order to identify the API endpoint is vulnerable to Broken Object Property Level Authorization, Sensitive properties exposure of certain object for non-intended user (Excessive Data Exposure). import requests # Assuming the API endpoint for retrieving user data is /api/users api_endpoint = "https://example.com/api/users" # Sending a GET request to the API endpoint response = requests.get(api_endpoint) # Checking if the request was successful (status code 200) if response.status_code == 200: # Printing the response content (which could contain excessive data) print(response.json()) else: print("Failed to retrieve data from the API") API allow to change, add or delete sensitive object property for non-intended user (Mass assignment). import requests # Assuming the API endpoint for updating user information is /api/users api_endpoint = "https://example.com/api/users" # Malicious payload containing additional fields malicious_payload = { "username": "malicious_user", "password": "password123", "isAdmin": True # Malicious user attempts to elevate privileges } # Sending a POST request with the malicious payload response = requests.post(api_endpoint, json=malicious_payload) # Checking if the request was successful (status code 200) if response.status_code == 200: print("User information updated successfully") else: print("Failed to update user information") Object Property Level Authorization involves controlling access to specific properties or attributes of an object within a system. Instead of granting blanket access to an entire object, this approach enables fine-grained control, allowing administrators to restrict or permit access to individual properties based on user roles or permissions. While implementing protection against such security risk involves different aspects, one is making sure the user is authorized to access object property, and here BIG-IP APM plays crucial role. Mitigating Risks with BIG-IP APM BIG-IP APM per-request granularity. With per-request granularity, organizations can dynamically enforce access policies based on various factors such as user identity, device characteristics, and contextual information. This enables organizations to implement fine-grained access controls at the API level, mitigating the risks associated with Broken Object Property Level Authorization. Key Features: Dynamic Access Control Policies: BIG-IP APM empowers organizations to define dynamic access control policies that adapt to changing conditions in real-time. By evaluating each API request against these policies, BIG-IP APM ensures that only authorized users can access specific resources and perform permitted actions. Granular Authorization Rules: BIG-IP APM enables organizations to define granular authorization rules that govern access to individual objects or resources within the API ecosystem. By enforcing strict authorization checks at the object level, F5 APM prevents unauthorized users from tampering with sensitive data or performing unauthorized actions. Conclusion In conclusion, BIG-IP APM per-request granularity is a powerful tool for defending against Broken Object-Level Authorization vulnerabilities in APIs. By enforcing fine-grained access controls at the API level, organizations can mitigate the risks associated with unauthorized access to sensitive data. Additionally, proactive security assessments and vulnerability scans are essential for identifying and addressing vulnerabilities in APIs, thereby strengthening overall security posture in the digital ecosystem. Related Content F5 BIG-IP Access Policy Manager | F5 Introduction to OWASP API Security Top 10 2023 OWASP Top 10 API Security Risks – 2023 - OWASP API Security Top 10 API Protection Concepts OWASP Tactical Access Defense Series: How BIG-IP APM Strengthens Defenses Against OWASP Top 10 OWASP Tactical Access Defense Series: Broken Object Level Authorization and BIG-IP APM F5 Hybrid Security Architectures (Part 5 - F5 XC, BIG-IP APM, CIS, and NGINX Ingress Controller) OWASP Tactical Access Defense Series: Broken Authentication and BIG-IP APMMitigation of OWASP API Security Risk: Unrestricted Access to Sensitive Business Flows using F5 XC
We have already covered different OWASP API risks in our previous articles (check reference section for more details). OWASP continuously analysed API threats in the last few years and has identified new types of risks which are not part of API Security Top 10 - 2019 edition. So, they added these new ones in the 2nd edition of OWASP API Security Top 10 2023 list and this article will cover the nuances of the newly added risk: Unrestricted Access to Sensitive Business Flows. Introduction: API owners should be very cautious of all the API endpoint’s exposed to users and they should identify each endpoint’s business justification. When developing an API Endpoint, we shall understand API use case and its intended scope of user action. Some business flows need to be monitored, restricted or blocked depending on the sensitivity of endpoint data. If any sensitive business flow is not protected, attackers can exploit them and cause some serious damage to the business. Using wide variety of automated tools available in market, hackers can automate the manual process thereby adversely impacting the genuine business workflows. That’s all the theory I have !!. Let’s plunge into a demo application use case and discover how F5 Distributed Cloud Platform (XC) can detect and guard our API application endpoints against this vulnerability. Use case: As part of testing, I was exploring the options available in one of the demo application “F5AIR” which is used for booking some dummy flight tickets and as a promotion this application is also offering 200$ as account balance after every user signup. In the 3rd tab we observed that this balance can be used to create gift cards which can be redeemed by users. After doing thorough research we have identified there are no restrictions on this workflow and it can be exploited using automated tools. Automated tools can be used to create multiple users, generate gift cards from each user and then redeem them into a single valid account to further book flight tickets without paying anything. Because of this risk, businesses can incur losses and so this is marked as a sensitive business flow. Artificial Intelligence is a truly disruptive technology spreading like wildfire and so for the purpose of today’s demo, I am using AXIOM.AI browser extension to automate the above manual workflow steps. It just took me around 30 minutes to understand how it works and was able to automate the above exploited manual steps. After 10 user creations and redeeming their gift cards valid main user will have around 2000$ which can be used to book flight tickets. Note: To showcase how AI tools can be leveraged to exploit modern applications we are using axiom ai tool and intended only for educational purposes. Mitigation Steps: A straightforward one-point solution may not be appropriate for different types of these vulnerabilities. Secops team should dig deeper into their incoming application traffic, differentiate genuine & malicious security data and then identify the API endpoints which are sensitive to their business flows. Once they have analyzed the traffic then they can apply below solutions as per their requirements Configure API Discovery to detect different API vulnerabilities like sensitive Data, API Attributes like Login page, Zombie API, security Posture, etc. You can find more details in this article Configure rate limiting on the sensitive business end points to keep a limit on number of requests - check here for more details on rate limiting Configure API Protection rules for these business API’s to restrict access to applications – check here for more details on API rules Configure Bot Defense to prevent bot attacks – check here for more details on bot protection As an example, let’s consider the above demonstrated AI tool example, to block any bots from accessing demo application we can apply bot defense configurations in root folder location “/” as shown below after which bot AI exploit requests can be mitigated. Note: Above config is for this article’s use case, but users must understand the API endpoint’s which should be protected and apply configs appropriately. We can also try other automation tools like postman which may also be blocked as below In F5 XC console if we navigate to this load balancer security events and bot defense dashboards, we can see these requests are blocked. Conclusion: In this article we explored some insights on this newly added OWASP API Security Top 10 risk, then we shed some light on how AI tools have opened floodgates to a new approach of application threats. Finally, we also revealed the final puzzle of how F5 XC Bot defense can become our elixir in identifying and protecting against this OWASP API risk along with novel AI threats. For more information or to get started check links below: OWASP API Security Top 10 2023 OWASP API Security Top 10 - 2019 F5 Distributed Cloud WAAP
OWASP Tactical Access Defense Series: Broken Authentication and BIG-IP APM
The threat of broken authentication poses a significant risk to organizations, potentially leading to unauthorized access and data breaches. In the face of this formidable challenge, F5's Access Policy Manager (APM) emerges as a robust and indispensable solution. By seamlessly integrating advanced authentication mechanisms and comprehensive access controls, F5 BIG-IP APM stands as a stalwart guardian against the vulnerabilities associated with broken authentication. This article explores the pivotal role played by BIG-IP APM in fortifying authentication protocols, mitigating risks, and ensuring a resilient defense against unauthorized access, ultimately safeguarding the integrity and security of sensitive data in today's dynamic digital environment. Broken Authentication Authentication mechanism is an exposed target due to the nature of this function, as authentication is the first point of entry to any platform. The difficulty to exploit authentication weaknesses differs based on how the authentication platform is secured. In the current digital era the security perimeters are very fluid, and so are the trust boundries for our authentication platforms those require more cautions from the developers and security architects regarding authentication flows. Not only we need to protect authentication endpoints and flows, but also some overlooked items like forget and reset password endpoints. How can we consider endpoint to be vulnerable? Credential stuffing. Brute force attacks targetting users' accounts. Weak Passwords. Sensitive details in the URL (passwords, Tokens). Allow users sensitive actions without confirmation. No validation for the tokens authenticity. Accept unsigned or weak jwt tokens. No validation for jwt expiration. Use of plain-text, non-encrypted or non-hashed passwords. Use of weak encryption algorithms. Endpoint can access each other without proper authentication. Use weak or predictable tokens for intra-endpoint authentication. Broken Authentication Examples Making use of GraphQL query patching to bypass API ratelimiting and brute force user's login. POST /graphql [ {"query":"mutation{login(username:\"victim\",password:\"password\"){token}}"}, {"query":"mutation{login(username:\"victim\",password:\"123456\"){token}}"}, {"query":"mutation{login(username:\"victim\",password:\"qwerty\"){token}}"}, ... {"query":"mutation{login(username:\"victim\",password:\"123\"){token}}"}, ] Update / modify user's sensitive information without API authorization token. PUT /account Authorization: Bearer <token> { "newpassword": "<new_password>" } BIG-IP APM and Broken Authentication We start with creating our Per-Request policy, this policy works in a different way than the per-session policy, as the flow will be evaluted on a per-request basis, making sure to consider variations throught the session life-time. Below are some of the key benefits: Wide range of Authentication, SSO, and MFA mechanisms to properly identify the initiating machine or user. Ability to integrate with 3rd parties to provide additional enforcement decisions based on the organization's policy. Ability to apply endpoint checks on the client side before session initiation. This goes to BIG-IP in general, the ability to apply custom traffic control on both of the traffic sides, Client and Server. The ability to create whitelist / blacklist for API Access tokens, JSON Web Tokens ID (JTI) or a different element based on the used authentication method, below example steps for JWT: Extract JTI value from Access token. Add JTI value to whether Allow/Block lists. Related Content F5 BIG-IP Access Policy Manager | F5 Introduction to OWASP API Security Top 10 2023 OWASP Top 10 API Security Risks – 2023 - OWASP API Security Top 10 API Protection Concepts OWASP Tactical Access Defense Series: How BIG-IP APM Strengthens Defenses Against OWASP Top 10 OWASP Tactical Access Defense Series: Broken Object Level Authorization and BIG-IP APM F5 Hybrid Security Architectures (Part 5 - F5 XC, BIG-IP APM, CIS, and NGINX Ingress Controller)F5 Distributed Cloud (XC) API Security in Out-of-Band Mode using BIG-IP
Introduction There are API Security use cases, which need to be deployed in out-of-band mode. An example of such use cases is an existing very high-critical API deployment, which cannot risk a new inline point. Another example is API security visibility deployment with so many deployment points, which renders new inline/proxy points becoming too expensive. F5 Distributed Cloud (XC) API Security solution by default, requires an inline deployment to be the most effective solution. It needs a different approach if out-of-band deployment is required. Out-of-band mode in this context, means that F5 XC is deployed outside of the API traffic path flow. This implies that F5 XC is in monitoring mode by receiving the API traffic from mirroring devices or API logging systems. While in monitoring mode, it cannot provide any protection or enforcement without any integration with existing security solutions; inline or F5 XC deployment is changed to be inline mode. The best deployment position for F5 XC API Security remains the inline mode. Architecture F5 XC is designed to be an inline solution. It receives the API request traffic, analyzes it, and forwards it to the backend/origin servers. Receives the API response traffic, analyzes it, and forwards it to the clients. F5 XC is not designed to handle API logs or mirrored traffic. Hence, it requires a separate component to receive the API logs or mirrored traffic and translate them into API request and response traffic, and send them to F5 XC. The architecture below uses BIG-IP as the separate component carrying out the needed functions. The above architecture takes an example of Apigee API Gateway platform, which sends an API trace in XML format containing the request and response traffic of an API call passing through it to a BIG-IP VE (Virtual Edition) deployed in AWS. The BIG-IP VE is licensed with LTM and configured with 3 virtual servers and 3 iRules to carry out the required functions. Step (1): BIG-IP VE receives the uploaded API trace in XML format via vs_log_receiver VS attached with an iRule 01_incoming_xml_to_log_converter. The iRule parses the trace, captures the API request and response traffic, create+save the simulated API response in the cache, create a unique link ID, create a simulated API request, and send the simulated API request to vs_http_to_https using Sideband iRule. Step (2): The vs_http_to_https VS receives the simulated API request traffic and forwards it as an HTTPS request to F5 Distributed Cloud (XC). F5 XC receives the simulated API request and forwards it back to the BIG-IP VE. Step (3): The BIG-IP VE receives the simulated API request from F5 XC, finds the corresponding API response from the cache using the unique link ID inside the request header, and sends the simulated API response to F5 XC. F5 XC then forwards the simulated API response to the BIG-IP VE completing the traffic flow cycle. With those steps, they mimic the situation where F5 XC receives normal API request and response traffic. The difference here is that the client and the server are the simulated one, not the real client and server. F5 XC processes the API traffic according to the API security configuration in a more passive role instead of an active role. The iRules are available at this link. Benefits The benefits of this architecture are: Deploy F5 XC API Security in out-of-band mode without disturbing/changing the existing API traffic flow, which makes the deployment faster and less intrusive. Get the API Discovery from F5 XC to discover API traffic endpoints and provide the analysis. Verify the API Authentication in each API request traffic. Conduct API Security posture management. Display the API security visibility in centralized manner without changing the API environment. Create the right justification cases for the higher-management approval to deploy the F5 XC API Security solution in inline mode. Get full support for the solution from F5 ecosystem because the solution uses standard F5 solution components. Scaling If significant capacity is required to process the mirrored API traffic, it is possible to deploy multiple BIG-IP VE instances and load-balance them using AWS Network Load Balancer. A specific iRule to synchronize the response cache entries between BIG-IP VE instances needs to be developed. I leave this scope for further details on implementation. Let me know your thoughts by leaving a comment or two below 🙂
