SPAMMING THROUGH FLOATING IP

We  noticed we are getting SPAM mails , when we checked it was noticed that the sender IP is our System floating IP of F5.

Required now is to get the real IP relaying the SPAM email

    • FAJUMO's avatar
      FAJUMO
      Icon for Cirrus rankCirrus

      Hello Kees,

      I am new to irule.

      saw this irule from your link. but do not know where to add the SMTP IPS here as they are 3 10.161.18.21-23

    • FAJUMO's avatar
      FAJUMO
      Icon for Cirrus rankCirrus

      Hello Kees,

      Thanks for much.

      The mail issue is tat we do not know the VS relaying the SPAM ail through. W are just seeing the floating IP as the initiator.

      How do i assign this Irule since the Virtual server is not knowm









  • You have to login to the BIG-IP web Gui, goto local traffic -> Virtual servers and look for the virtual server with port 25.

    • FAJUMO's avatar
      FAJUMO
      Icon for Cirrus rankCirrus

      Hello Kess,

      I have seen the VS,and need to apply this irule to it

      Advice if this irule is okay

      when RULE_INIT {

      set static::smtp_debug 1

      set static::route_domain_id 1

      }

      when CLIENT_ACCEPTED {

      if {[class match [getfield [IP::client_addr] % 1] equals internal_IP]} {

      } else {

      drop

      return

      }

      STREAM::expression {@[hH][eE][lL][oO] .*[[:cntrl:]][[:cntrl:]]@@ @[eE][hH][lL][oO] .*[[:cntrl:]][[:cntrl:]]@@ @[.][[:cntrl:]][[:cntrl:]]@@ @354 End data with @@ @250 2.0.0 Ok: queued as @@}

      STREAM::enable

      set disable_matching 0

      }

      when STREAM_MATCHED {

      switch -glob [STREAM::match] {

      "354 End data with " {

      incr disable_matching

      STREAM::replace

      return

      }

      "250 2.0.0 Ok: queued as " {

      STREAM::replace

      return

      }

      default {

      set mstring_hex ""

      set mstring_hex_trimmed ""

      set mstring_ascii ""

      set c_initiation_string_hex_trimmed ""

      set detected_c_initiation_string ""

      binary scan [STREAM::match] H* mstring_hex

      set mstring_hex_trimmed [string range $mstring_hex 0 end-4]

      set mstring_ascii [binary format H* $mstring_hex_trimmed]



      if { $mstring_ascii eq "\." } {

      set disable_matching 0

      STREAM::replace

      return

      }

      if { $disable_matching > 0 } {

      STREAM::replace

      return

      }

      if { ( [string tolower $mstring_ascii] starts_with "helo " ) or ( [string tolower $mstring_ascii] starts_with "ehlo " ) } {

      set c_declared_id [string range $mstring_ascii 5 end]

      }

      if { $c_declared_id contains "\[" } {

      set c_declared_id [ string map [ list \[ "" \] "" ] $c_declared_id ]

      }

      set a null

      set b null

      set c null

      set d null

      scan $c_declared_id {%d.%d.%d.%d} a b d c

      if { !($a == "null") && !($b == "null") && !($c == "null") && !($d == "null") } {

      if { (0 <= $a) && ($a <= 255) &&

      (0 <= $b) && ($b <= 255) &&

      (0 <= $c) && ($c <= 255) &&

      (0 <= $d) && ($d <= 255) } {

      if { $static::route_domain_id != 0 } {

      append c_declared_id "%" $static::route_domain_id

      }

      if { not ( $c_declared_id equals [IP::client_addr] ) } {

      drop

      return

      }

      }

      } else {

      if { ! ( $c_declared_id contains "\." ) } {

      drop

      return

      }

      if { $static::route_domain_id != 0 } {

      set resolved_addrs [RESOLV::lookup @172.18.240.210%$static::route_domain_id -a $c_declared_id]

      } else {

      set resolved_addrs [RESOLV::lookup @172.18.240.210 -a $c_declared_id]

      }

      if { not ( $resolved_addrs equals "" ) } {

      set addr_matched 0

      foreach resolved_addr $resolved_addrs {

      if { $static::route_domain_id != 0 } {

      append resolved_addr "%" $static::route_domain_id

      }

      if { $resolved_addr equals [IP::client_addr] } {

      incr addr_matched

      break

      }

      }

      if { $addr_matched < 1 } {

      drop

      return

      }

      } else {

      drop

      return

      }

      }

      STREAM::replace

      return

      }

      }

      }



      when SERVER_CONNECTED {

      STREAM::expression {@354 End data with @@ @250 2.0.0 Ok: queued as @@}

      STREAM::enable

      }

  • Yes it is. Before applying it to the virtual server you have to attach a stream profile to the virtual server.
