Forum Discussion

PARMAR_289528's avatar
PARMAR_289528
Icon for Nimbostratus rankNimbostratus
Sep 08, 2016

Server Pool not coming up in Big Ip LTM VE(virtual edition) 90 days trial version

Hi ,   I am setting up a Big-Ip lab using the Big Ip LTM VE(virtual edition) 90 days trial version, I am following the Keith Barker CBT nuggets to create the lab and using his resources provided i...
application delivery
LTM
Samir_Jha_52506's avatar
Samir_Jha_52506
Icon for Noctilucent rankNoctilucent
Apr 21, 2017

Reviewed above post but no where seen curl output. I believe back-end server is up & port is not learning with HTTP service.

Check below thing to troubleshoot further. 1) Directly hit to back end server through browser and check you are getting page

 http://x.x.x.x:80     --> Here x.x.x.x will be back end server IP with 80 port



2) Attach curl & telnet output to check further

   curl -gv http://x.x.x.x:80
   telnet x.x.x.x:80

Does it makes sense?

plethore_312934's avatar
plethore_312934
Icon for Cirrus rankCirrus
Apr 21, 2017

I had a similar issue, when using the 90 day trial for the CBT Nuggets lab, the Pool would show down. What my issue was the default HTTP monitor being used.



I created a new monitor under Local Traffic -> Monitors



Name http_11.3



Parent Monitor - http



Send String: GET / HTTP/1.0\r\n\r\n



Leave other options as the defaults.



Then under Local Traffic -> Pool choose the OUR-WEB-SERVER pool. In the Health Monitors section add the http_11.3 monitor and remove the http monitor, and make sure to update the configuration.



See if that works.
