DevCentral Connects - Sep 27, 2022 - Open Programmable Infrastructure
Resources Full OPI Interview with Joel Moses Linux Foundation OPI Announcement OPI Project on GitHub In The News State of Application Strategy Survey The Codeshare is Back! September Featured Member - Pascal Küppers A History of ARM Part 1 Adding with Logic Gates What's New in Security in Kubernetes 1.25 Uber / RockStar Games Hacker Arrested
DevCentral Connects Livestream - Tuesdays 8:30AM Pacific
DevCentral Connects, our flagship livestream, is moving to Tuesdays 8:30AM PT. We’re moving it up an hour and adding an hour from 9a-10a on theF5 DevCentralPlatform –Community.f5.com– for you to join us backstage for the DevCentral Connects Aftershow! Join us every Tuesday at 8:30am PT and from 9a-10a for the Community Hour Aftershow! Links in the description get you there! DevCentral Connects is now LIVE every Tuesday 8:30AM PT. Show link: https://www.youtube.com/watch?v=1LX_i1loKM8&list=PLyqga7AXMtPNqLSMnobhuoRMMR013T2s_&ab_channel=F5DevCentral Aftershow link: https://community.f5.com/t5/devcentral-connects/gh-p/DevCentralConnectsRewriting iRules...LIVE!
We host four shows on Tuesdays at 9:30am pacific every month. This November, we had a bonus Tuesday, so Buu and decided to try something new: live coding with the audience through Visual Studio Code's live sharing extension! Now, I've written iRules for many years, but in the past few that work has given way to more iControl and other automation tools, so whereas I am a little rusty, I still enjoy the experience. In the show, which you can watch in replay below, we walked through the progression of four versions of the DNS Flood Rate Limiting iRule out in the codeshare before settling in to rewrite this iRule from the iRules Toolbox on Github. Original State The iRule evaluates the HTTP host and uri, and if there's a match, rewrites them both. Here's the original form: when HTTP_REQUEST { #find a match using host+uri against the class and #returns the whole string (field1 field2 field3)then #set it as newURI variable. set newURI "[findclass [HTTP::host][HTTP::uri] $::redlist]" if { $newURI ne "" } { # Parse the three fields in the matched datagroup line scan $newURI {%s %s %s} unused host uri #change host and uri if {$host ne ""}{ HTTP::header replace Host $host } if {$uri ne ""}{ HTTP::uri $uri } } } We talked during the show about the findclass command and that it's been deprecated for quite some time, and that the $::data-group-name format utilized is also deprecated and even if it wasn't, would not be a good idea as it would demote the virtual server from CMP. Another thing that jumped out at me was the independent checks on the host and uri, as I'm not sure the original intent would be to rewrite one without the other, but without the context of the original problem it's hard to tell. Finally, the scan, which is an awesome command, takes the input from the data-group and stores the values in three separate variables, one of which, aptly named, is unused. Final State I simply LOVE the interaction that the live stream coupled with the VS Code live sharing provided. Daniel Wolf and Josh Becigneul, in their engagements, added a couple insights to what is the final state that I would not have included in my version if coding this solo. First, the data group and the iRule, and then some comments. The original data group seemed to have a format without key/value pair, but it’s hard to tell since it wasn’t provided. That said, It makes more sense to me, and Daniel Wolf also alluded to this, to have the record name be the string we’re matching and for the data to be the new host/uri, separated by a single whitespace. # ltm data-group internal redlist { # records { # testvip.test.local/testpath/img.png { # data "newtestvip.test.local /newtestpath/img.png" # } # } # } when HTTP_REQUEST priority 501 { if { [HTTP::has_responded] } { return } else { scan [class match -value -- [HTTP::host][string tolower [HTTP::uri]] starts_with redlist] {%s %s} host uri if {($host ne "") and ($uri ne "") } { HTTP::header replace Host $host HTTP::uri $uri } } } The rewrite kicks off with a mention in the comments from Josh about making sure the BIG-IP, either by policy or other iRule, hasn’t already responded. These soft errors used to drive me batty trying to locate them when I was operationally responsible for DevCentral and adopted 10+ iRules running on a single virtual doing a myriad of things. This is a newer command to handle the problem, and I’m grateful for it. Nice callout! Next, the sweet sauce is all consolidated into the scan command. From the inside out: Added a string tolower for the HTTP::uri so we don’t have to manage all those cases in a static data-group Replaced findclass with class match Since using HTTP::uri instead of HTTP::path, used starts_with operator instead of equals Utilized -value to return the data within the record instead of just a boolean Utilized -- to prevent additional arguments With scan, since we optimized the data-group, we only need to store the host and uri and don’t have to handled the record name at all. Finally, before doing a header replace or rewriting the URI, I check to make sure neither is an empty string, so they’re coupled together. This may or may not have been the original intent, but it’s the logic choice I’m making here in the update. Not necessary for the logic that we’re rewriting, but I added this event below to test the changes above since I didn’t want to test actual server URI stuff. # This lower priority request event is strictly for testing the iRule, it is not intended for rollout when HTTP_REQUEST priority 502 { HTTP::respond 200 content "New Host: [HTTP::header Host], New URI: [HTTP::uri]" } And with that, we can fire up one of my Today I Learned segments in VS Code, the Thunder Client, to run a quick test. You can see in the client that I am inserting a host header since I am testing the URL to an IP address of my test box, and that I am using the URI I intend to match from the data-group above. And finally, in steps 3 and 4, the results we expect to see as a result of the iRule logic. Huzzah! Conclusion This was a super fun show to do, and we loved the engagement. Rewriting things is also a great way to skill build. Sometimes the most daunting task is an empty screen. It's like BASF used to say in their commercials, "We don't make the products you buy, we make the products you buy better." In that vein, if you want to skill build, go out to the iRules Toolbox on Github and check over all the 20 Lines or Less iRules and start making them better. It'll make YOU better in the process. Until next time...F5 2021 Agility Live! - with Jason and John
Some more Details(Update 4/19) Agility starts tomorrow - it's not too late to register and find the sessions that most meet your needs. The opening Keynote starts at 8AM (re-air at 6PM) Pacific Ask The CTO panel starts at 12:noon Pacific And...of course Agility Live! with Jason and John at 3PM to recap the day. We are looking forward to a great week. ----- During F5 Agility 2021 (April 20-22) you can join Jason and John for any (or all) of the four scheduled Agility Live! sessions.Register for Agility 2021 here and add Agility Live! to your Agenda.
