How to get group name CN from session.ad.last.attr.memberOf when there are multiple attribute value

Hi all,

When I use the session.ad.last.attr.memberOf variable the group values are like:

saml2:Attribute Name="groups"

saml2:AttributeValue CN=webaccess,OU=Users,OU=mydomain,DC=com /saml2:AttributeValue

saml2:AttributeValue CN=webtest,OU=Users,OU=mydomain,DC=com /saml2:AttributeValue

saml2:AttributeValue CN=webfort,OU=Users,OU=mydomain,DC=com /saml2:AttributeValue

saml2:AttributeValue CN=webui,OU=Users,OU=mydomain,DC=com /saml2:AttributeValue

/saml2:Attribute"

The question is how can I strip the first group name CN part from each attribute value in a APM access policy using the variable assign element? So in the example above I only need webaccess webtest webfort webui like below.

"saml2:Attribute Name="groups"

saml2:AttributeValue webaccess/saml2:AttributeValue

saml2:AttributeValue webtest /saml2:AttributeValue

saml2:AttributeValue webfort/saml2:AttributeValue

saml2:AttributeValue webui/saml2:AttributeValue

/saml2:Attribute"

I have tried multiple scripts but not getting desired result,
1.

"set mem_fields [split [mcget {session.ad.last.attr.memberOf}] "|"]; foreach mem $mem_fields { if { $mem contains "CN" } { set found $mem } }; set grp_fields [split $found "=,"]; return [lindex $grp_fields 1];"

used this, but the output is, just the first CN name

"saml attribute value webaccess /saml atrribute value"

==============================================

"set newGroups [list]
foreach group [mcget {session.ad.last.attr.memberOf}] {
if {[regexp {CN=([^,]+)} $group - cn]} {
lappend newGroups $cn
}
}
set session.sso.token.last.attr.groups $newGroups

output is

saml attribute value webaccesswebfortwebtestwebui/saml attribute value"

3. "set newGroups [list]
foreach group [mcget {session.ad.last.attr.memberOf}] {
    if {[regexp {CN=([^,]+)} $group - cn]} {
        lappend newGroups $cn
    }
}
set session.custom.group_cns [join $newGroups "\n"]

output is

saml attribute value webaccess

webfort

webtest

webui/saml attribute value"

Any help is much appreciated.

application delivery

Injeyan_Kostas

Jun 17, 2025

I found an error though causing duplicate entries

you can use this one as custom expression

set result ""
set groups [mcget {session.ad.last.attr.memberOf}]
foreach {full match} [regexp -all -inline {CN=([^,]+)} $groups] {
    append result "| $match "
}
append result "|"
return $result

9 Replies

JoshBecigneul
MVP
Jun 01, 2025
Hi heenakhanam0708, can you provide any example/screenshot of the output from the variables via the Access -> Overview -> Active Sessions view?
- heenakhanam0708
  Altocumulus
  Jun 17, 2025
  Dear JoshBecigneul ,
  The variable output is as below,
  | CN=webaccess,OU=Users,OU=mydomain,DC=com | CN=webtest,OU=Users,OU=mydomain,DC=com | CN=webfort,OU=Users,OU=mydomain,DC=com | CN=webui,OU=Users,OU=mydomain,DC=com |
Injeyan_Kostas
Cumulonimbus
May 30, 2025
Your session.ad.last.attr.memberOf variable should be like this:
| CN=webaccess,OU=Users,OU=mydomain,DC=com | CN=webtest,OU=Users,OU=mydomain,DC=com | CN=webfort,OU=Users,OU=mydomain,DC=com | CN=webui,OU=Users,OU=mydomain,DC=com |

This
saml2:Attribute Name="groups" saml2:AttributeValue CN=webaccess,OU=Users,OU=mydomain,DC=com /saml2:AttributeValue saml2:AttributeValue CN=webtest,OU=Users,OU=mydomain,DC=com /saml2:AttributeValue saml2:AttributeValue CN=webfort,OU=Users,OU=mydomain,DC=com /saml2:AttributeValue saml2:AttributeValue CN=webui,OU=Users,OU=mydomain,DC=com /saml2:AttributeValue /saml2:Attribute"
Is what is injected in SAML assertion which I assume you are using

So your goal is to modify this:
| CN=webaccess,OU=Users,OU=mydomain,DC=com | CN=webtest,OU=Users,OU=mydomain,DC=com | CN=webfort,OU=Users,OU=mydomain,DC=com | CN=webui,OU=Users,OU=mydomain,DC=com |

To this:
| webaccess | webtest | webfort | webui |
And then SAML assertion will be ok also

So, you can create a new custom valiable, in you example “session.sso.token.last.attr.groups”
And you as custom expression
set result "" foreach match [regexp -all -inline {CN=([^,]+)} [mcget {session.ad.last.attr.memberOf}]] { regexp {CN=([^,]+)} $match dummy cn append result "| $cn " } append result "|" return $result

of course add to SAML attributes this new custom valiable
- heenakhanam0708
  Altocumulus
  Jun 17, 2025
  Dear Injeyan_Kostas , it seems the session.ad.last.attr.memberOf is just like how you showed.

  | CN=webaccess,OU=Users,OU=mydomain,DC=com | CN=webtest,OU=Users,OU=mydomain,DC=com | CN=webfort,OU=Users,OU=mydomain,DC=com | CN=webui,OU=Users,OU=mydomain,DC=com |

  and its not presenting anything in the SAML response,
  After using your expression, I am getting like this in the variable output,
  | webaccess | webtest | webfort | webui |

  and in the SAML response, like this
  saml2:AttributeValue webaccess | webaccess | webtest | webfort | webui | /saml2:AttributeValue

  But the requirement is,
  saml2:AttributeValue webaccess /saml2:AttributeValue
  saml2:AttributeValue webtest /saml2:AttributeValue
  saml2:AttributeValue webfort /saml2:AttributeValue
  saml2:AttributeValue webui /saml2:AttributeValue
  Its a single attribute with multiple values, and it should be presented as multiple values in plain text
  - Injeyan_Kostas
    Cumulonimbus
    Jun 17, 2025
    heenakhanam0708 could you please check for typos in your config
    I just retest it and works fine, at least in my env

    moreover in your first post you said that by default you see
    saml2:Attribute Name="groups"
    saml2:AttributeValue CN=webaccess,OU=Users,OU=mydomain,DC=com /saml2:AttributeValue
    saml2:AttributeValue CN=webtest,OU=Users,OU=mydomain,DC=com /saml2:AttributeValue
    saml2:AttributeValue CN=webfort,OU=Users,OU=mydomain,DC=com /saml2:AttributeValue
    saml2:AttributeValue CN=webui,OU=Users,OU=mydomain,DC=com /saml2:AttributeValue
    /saml2:Attribute"

    How it's not showing anything now when use session.ad.last.attr.memberOf ?
